LANVIEW LEDs
Table 2-1 Power Supply (PS) LED Status Definitions
Condition PS1
1 ON
2 OFF
3 ON
4 Out of chassis
5 ON
6 ON
2.3.2

Fan Tray LED

Refer to Figure 2-3
the fan tray LED.
Figure 2-3 Fan Tray LED
Table 2-2 Fan Tray LED States and Their Definitions
LED Color
Green
Red
NOTE: When the Matrix E7 is first powered up, the Fan Tray LED will display red briefly,
until the fans are operating at the proper speed.
2-4
PS2
OFF
ON
Out of chassis
ON
ON
ON
for the location of the fan tray LED.
Status
All fans are operating normally.
One or more fan failures have occurred.
Load PS1 LEDs
PWR FAN
Amber Green
Red Red
Green Green
Off Off
<50% Green Green
>50% Amber Green
Table 2-2 describes the different states of
PS2 LEDs
PWR FAN
Red Red
Amber Green
Off Off
Green Green
Green Green
Amber Green
