Setting Up the Matrix E7 Chassis
3.2.3

Rack Mounting the Matrix E7 Chassis

The Matrix E7 chassis can be mounted in a standard 48.26-centimeter (19-inch) equipment rack.
To rack mount the chassis into a rack you need to
•
allow at least 60 centimeters (24 inches) of clearance in front of the rack for chassis installation,
•
install the shelf into the rack first, then
•
install the Matrix E7 chassis into the chassis.
3.2.3.1

Installing the Shelf

To install the shelf, proceed as follows:
CAUTION: If the rack is not secured to the floor, it is recommended that you install the
chassis in the bottom half of the rack. This helps prevent the rack from being top heavy.
1. Keeping the above Caution note in mind, locate the position on the rack where you will install
the shelf. The chassis requires 77.47 centimeters (30.5 inches) of vertical spacing.
2. Align the four holes in the ears of the shelf with those in the rack (see
the shelf to the rack using four of the screws supplied with the rack.
3. After installing the shelf, proceed to install the Matrix E7 chassis as described in
3-6
Figure 3-3, A), then fasten
Section 3.2.3.2.
