Configuration Guidelines

•
Ambient temperature at the installation site must be maintained between 5° and 40°C
(41° to 104°F). Temperature changes must be maintained within 10°C (18°F) per hour.
2.2 CONFIGURATION GUIDELINES
The Matrix E7 chassis has seven slots that accept interface modules. The slots are numbered 1 to 7
beginning with the leftmost slot. There are two slots near the bottom of the chassis that are strictly
for power supplies. These slots are labeled PS1 and PS2.
NOTE: The 3rd Generation (6x3xx series) interface modules are designed for the
Matrix E7 chassis, and can be inserted in any of the 7 slots of the Matrix E7. The
previous generation boards (6x1xx and 6x2xx series), can be inserted in slots 1 through
5, but should not be inserted in slot 6 or 7, if backplane connectivity is desired.
Refer to Section 3.2.5
Modules for the Matrix E7 chassis are equipped with a firmware-based management tool called
Local Management, which provides the capability to configure the module; and access chassis,
power supply, and fan tray information. WebView can also be used for management of the
modules and the chassis.
2.3

LANVIEW LEDs

The following sections describe the LANVIEW LED indications for the following:
•
6C207-1 (Rev. OF) and 6C207-3 power supply modules
•
Fan tray unit
2.3.1

Power Supply LEDs

There are two LEDs on the power supply. Refer to
power supply LEDs.
different conditions. The power supplies are installed in chassis slots PS1 and PS2 in the
front-bottom part of the chassis.
NOTE: It is not recommended to install the 6C207-1 and 6C207-3 power supply
modules in the same chassis.
2-2
and the Release Notes for further guidance.
Table 2-1 describes the different states of the power supply LEDs under six
Figure 2-1 and Figure 2-2 for the location of the
