Unpacking the Matrix E7 Chassis

3.1 UNPACKING THE MATRIX E7 CHASSIS
NOTE: Unpack the Matrix E7 chassis components only as needed. Leave the
components in their respective shipping cartons until you are ready to install that
component.
CAUTION: Observe all Electrostatic Discharge (ESD) precautions when handling
sensitive electronic equipment.
To unpack the Matrix E7 chassis, proceed as follows:
1. Unpack the Matrix E7 chassis by carefully removing it from the shipping box. (Save the
shipping box and materials in the event the chassis has to be reshipped.)
2. Remove the chassis from the protective plastic bag.
3. Examine the Matrix E7 chassis carefully, checking for damage. If any damage is noted, DO
NOT install the chassis. Contact Enterasys Networks immediately.
4. Remove the accessory package.
5. Remove the package containing the four rubber feet/screw assemblies.
6. Remove the Electrostatic Discharge (ESD) wrist strap package.
7. Remove the Console Cable Kit and set aside. This kit is needed to set up the Matrix E7 modules
through Local Management.
3-2
