Figure 3-3 Shelf Installation
3.2.3.2 Installing the Matrix E7 Chassis
CAUTION: Read
all installation guidelines are met.
To install the Matrix E7 chassis, proceed as follows:
CAUTION: To help prevent personal injury, at least two people are required to lift the
chassis into the rack.
1. Lift the chassis onto the shelf and slide it all the way into the rack. Refer back to
Chapter 2 before completing the following procedure to ensure that
Setting Up the Matrix E7 Chassis
Figure 3-3, B.
3-7
