48'' Belt Drive Cone Fan
About This Manual
Important !
Important !
MV1600B
The intent of this manual is to help you in two ways. One is to follow step-by-step in
the order of assembly of your product. The other way is for easy reference if you have
questions in a particular area.
Read ALL instructions carefully before starting construction.
Pay particular attention to all SAFETY information.
• Metric measurements are shown in millimeters and in square brackets, unless
" " "
otherwise specified.
measurements.
Examples:
1'' [25.4]
• Optional equipment contains necessary instructions for assembly or operation.
• Major changes from the last printing will be listed on the back cover.
• This Planning Symbol is used in areas where planning needs to take place before
construction continues.
• Very small numbers near an illustration ( i.e.,
not a part number.
" ' "
equals inches and
equals feet in English
4' [1 219]
) are identification of the graphic,
1257-48
About This Manual
