The CE870 Instant Issuance System

C
B
A
A = Printer Component
B = Card Input Hopper
C = Swingarm
D = Printer Lock
E = Latch Button
F = Cover Ridges
G = Print Ribbon Cartridge Handle
H = Printer Supplies Access Door
Front Panel
Power
Button
527488-001D
D
P
O
I = Embosser Component
J = Embosser Supplies Access Door
K = Indent Cartridge
L = Embosser Lock
M = Topping Foil Cartridge
N = Multi-hopper Cover
O = Card Output Hopper
P = Front Panel
Up Enter
Down
Arrow
Arrow
User Reference Guide
E
F
G
M
N
LCD Front Panel
Status Lights
Ribbon
Cards
User Light &
User Button
H
I
J
K
L
