Table 5-2 Switch Information Variables (continued)
Variable
SwitchMirroredPort
SwitchMirroringPort
SwitchXmitMirrorEnable
SwitchRcvMirrorEnable
SwitchVlanEnable
SwitchVlanConfigTable
SwitchVlanId
SwitchVlanName
SwitchVlanPorts
SwitchVlanStatus
SwitchVlanEgressPorts
SwitchVlanStatus
SwitchVlanPortTable
SwitchVlanPortId
SwitchVlanPvid
SwitchVlanPortType
SwitchPriorityEnable
SwitchPriorityThreshold
SwitchPriorityPortTable
SwitchPriorityPortId
SwitchPriorityDefault
68 SNMP Management
Description
Port to be mirrored from.
Port to be mirroring to.
Enable/disable mirroring of transmitted traffic.
Enable/disable mirroring of received traffic.
Enable/disable global VLAN operation of the
switch.
Table indexed by SwitchVlanId
VLAN number or ID.
Text string for VLAN name.
Ports in the VLAN.
Variable used to add or delete entries from the
VlanConfigTable.
Ports to which traffic destined for this VLAN may
be transmitted.
Variable used to add or delete entries from the
VlanConfigTable.
Table indexed by SwitchVlanPortId.
Port number or ID.
Port VLAN ID (PVID) for this port.
The type of VLAN this port is operating as, either
hybrid or access.
Enable/disable global traffic priority in the
switch.
Priority threshold level (0-7) in the switch which
defines switch traffic to be high or low priority.
Priority table indexed by SwitchPriorityPortId.
Port number or ID.
Priority level (0-7) assigned to untagged traffic
entering the associated port.
ELS100-24TX
