Switch Configuration Menu

The Switch Configuration Menu allows you to modify switching-related
configuration parameters. Select b from the Main Menu to view the Switch
Configuration Menu. Figure 3-6 shows the Switch Configuration Menu
and the accompanying table describes the Switch Configuration Menu.
SWITCH CONFIGURATION
a. Forwarding Table Configuration Menu
b. Spanning Tree Configuration Menu
c. VLAN Configuration Menu
d. Class of Service Configuration Menu
e. Forwarding Table Aging Time(seconds)
f. Broadcast Cutoff Rate
g. Port Mirroring Enable
h. Mirrored Port
i. Mirroring Port
j. Transmit Data Mirror Enable
k. Receive Data Mirror Enable
x. Previous Menu
Enter Selection:
Figure 3-6. Switch Configuration Menu
Selection
Forwarding Table
Configuration Menu
Spanning Tree
Configuration Menu
VLAN Configuration Menu
Class of Service
Configuration Menu
Forwarding Table Aging Time
Broadcast Cutoff Rate
Port Mirroring Enable
Mirrored Port
Mirroring Port
Transmit Data Mirror Enable *
Receive Data Mirror Enable *
*Only one of these options can be enabled at any given time. Changing the setting
of one of these options automatically changes the setting of the other option.
28 ELS100-24TX User Interface
Access Control: READ/WRITE
300
500000
No
2
1
Yes
No
Description
Menu for configuring the switch forwarding table.
Menu for configuring the switch Spanning Tree
operation.
Menu for configuring the VLAN operation of the switch.
Menu for configuring Class of Service for the switch.
Time in seconds until entries in the filter table are aged
out if not accessed (10-1,000,000 second range).
Per second rate past which broadcast and destination
unknown unicast frames are not flooded on each
group of 8 ports on the switch (100-500,000 frames per
second range).
Allows you to enable (Yes) or disable (No) port
mirroring.
The source port for the data to be mirrored.
The destination port for the data to be mirrored.
Allows you to enable (Yes) or disable (No) the
mirroring of data transmitted out the mirrored port.
Allows you to enable (Yes) or disable (No) the
mirroring of data received by the mirrored port.
