SNMP Configuration Menu

The SNMP Configuration Menu allows you to modify SNMP-related
configuration parameters. Select a from the System Configuration Menu
to view the SNMP Configuration Menu. Figure 3-5 shows the SNMP
Configuration Menu and accompanying table describes the SNMP
Configuration Menu.
SNMP CONFIGURATION
a. SNMP Private Community Name
b. SNMP Public Community Name
c. Trap Destination #1
d. Community Name #1
e. Trap Destination #2
f. Community Name #2
g. Trap Destination #3
h. Community Name #3
i. Trap Destination #4
j. Community Name #4
x. Previous Menu
Enter Selection:
Figure 3-5. SNMP Configuration Menu
Selection
SNMP Private
Community Name
SNMP Public
Community Name
Trap Destination #1
Community Name #1
Trap Destination #2
Community Name #2
Trap Destination #3
Community Name #3
Trap Destination #4
Community Name #4
9032579-03
Access Control: READ/WRITE
private
public
000.000.000.000
public
000.000.000.000
public
000.000.000.000
public
000.000.000.000
public
Description
The community name for read/write SNMP access to the
device (1-10 character range; the default name is: "pri-
vate").
The community name for read only SNMP access to the de-
vice (1-10 character range; the default name is: "public").
The IP address of trap destination #1 where SNMP trap
messages are forwarded.
The SNMP community name to use for traps forwarded to
trap destination #1.
The IP address of trap destination #2 where SNMP trap
messages are forwarded.
The SNMP community name to use for traps forwarded to
trap destination #2.
The IP address of trap destination #3 where SNMP trap
messages are forwarded.
The SNMP community name to use for traps forwarded to
trap destination #3.
The IP address of trap destination #4 where SNMP trap
messages are forwarded.
The SNMP community name to use for traps forwarded to
trap destination #4.
ELS100-24TX User Interface 27
