VLAN Menu

The VLAN Menu displays the configuration of VLANs in the switch and
allows access to the VLAN #n Configuration Menu to create and configure
VLANs. Select b from the VLAN Configuration Menu to view the VLAN
Menu. Figure 3-12 shows the VLAN Menu and the accompanying table
describes the VLAN Menu.
VLAN MENU
ID VLAN NAME
-------------------------------------------------------------------------------------------------------
1 default
c. Configure
Enter Selection:
Field
ID
VLAN Name
Ports in VLAN
VLAN Egress Ports
Selection
Configure
Delete
36 ELS100-24TX User Interface
PORTS IN VLAN
1-24
d. Delete x. Previous Menu
Figure 3-12. VLAN Menu
Description
The identification number of the VLAN (1-4 character
range).
The administrative name assigned to the VLAN (1-14
character range; entering a VLAN name is not required).
The ports assigned to the VLAN.
The egress (exit) ports which link the ELS100-24TX to
other devices which also include members of the same
VLAN.
Description
Allows you to configure an existing VLAN listed in the
VLAN table, create a new VLAN (1-4094 numerical
range), and to open the VLAN #n Configuration Menu.
Allows you to delete a specific VLAN.
Access Control: READ/WRITE
VLAN EGRESS PORTS
None
ELS100-24TX
