Spanning Tree Configuration Menu (continued)
Selection
Spanning Tree Protocol
Enable
Port Configuration Menu
Hello Time (seconds)
Forward Delay
(seconds)
Max Age (seconds)
Bridge Priority
32 ELS100-24TX User Interface
Description
Allows you to enable (Yes) or disable (No) the global
Spanning Tree operation on the switch.
Provides access to the Spanning Tree Port Configura-
tion Menu.
The time interval between the sending of Configura-
tion BPDUs by the bridge, if it is root (1-10 second
range).
The time interval delay before a port transfers into the
forwarding state, if it is root (4-30 second range).
The maximum age of received protocol information
before it is discarded (6-40 second range).
A relative priority of bridges, with the lowest value
bridge ID indicating the highest priority (0-65535
range).
