Table 5-2. Switch Information Variables
Variable
SwitchIpAddress
SwitchSubnetMask
ActiveAgingTime
SwitchStpStatus
SwitchManager
SwitchTrapRcvr1
SwitchTrapCommunity1
SwitchTrapRcvr2
SwitchTrapCommunity2
SwitchTrapRcvr3
SwitchTrapCommunity3
SwitchTrapRcvr4
SwitchTrapCommunity4
SwitchPortMirroringStatus
9032579-03
Description
IP address of the switch, used for management.
Subnet mask corresponding to the
SwitchIPAddress.
Aging tick period in seconds by which addresses in
the forwarding table are aged out.
Enable/disable operation of Spanning Tree on the
switch.
List of SNMP trap manager IP addresses.
SNMP trap manager IP address #1.
SNMP community associated with trap manager IP
address #1.
SNMP trap manager IP address #2.
SNMP community associated with trap manager IP
address #2.
SNMP trap manager IP address #3.
SNMP community associated with trap manager IP
address #3.
SNMP trap manager IP address #4.
SNMP community associated with trap manager IP
address #4.
Enable/disable port mirroring operation of the
switch.
continued on next page
SNMP Management 67
