- Page 1 30 mins ITEM#HI4011-Z 1 YR LTD OFFICE CHAIR 1 Box H39.2"W22"D18.1"...
- Page 4 Silver Bolt Silver Bolt Black Bolt Ø6*20mm Ø6*30mm Ø8*30mm Allen Key Chair back Plastic arm decor Chair arms Metal base Gas bar Chair seat Caster Plastic cover Base...
- Page 6 Attach caster (9) on base (7) .(see photos for example) ● Insert plastic cover (8) on base (7). ●...
-
Page 7: Hardware Required
Attach gas bar (6) on base(7) .(see photos for example) ● Attach chair back(1) on chair seat(4), screw 2 X bolt (B) with allen key (E) after two holes ● aligned with screw holes on metal rod.(see photos for example) HARDWARE REQUIRED... - Page 8 Attach metal rod (3) on chair seat (4)and back(1),screw 2 X bolt(A) with allen key (D)in the holes ● after two holes on rod aligned with screw holes on chair back,seat.(see photos for example) Screw 4X bolt(B) with allen key (D)in the holes after two holes on rod aligned with screw holes on ●...
- Page 9 Step 7 Put chair seat (4) on top of gas bar(6) , let gas top into metal base(5) hole, sit on chair to let ● gas bar attach together .(see photos for example) Step 8 Tighten all screws after every part is in the right position; ●...
