- Page 1 Hodedah www.hodedah.com support @hodedah.com HI 917DM '' X D18'' X H76''...
- Page 2 Hodedah www.hodedah.com support @hodedah.com PART & HARDWARE LIST PLASTIC DOWEL M8 X 25MM PVC LEG STUD (L & R) CB SCREW M3.5 X 12MM PVC LEG STUD (SINGLE) CB SCREW M4 X 25MM CB SCREW M4 X 35MM DRAWER SLIDE 16"...
- Page 3 Hodedah www.hodedah.com support @hodedah.com - This product contains small components, please ensure that they are kept away from small children. - THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. DO NOT RETURN PRODUCT TO THE STORE.
-
Page 4: Helpful Hints
- Never push, drag or pull your furniture (especially on carpet). Warranty Information Hodedah warrants this product to be free from defects in material and workmanship agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to be repair or replacement of defective parts and no assembly labor is included. - Page 5 Hodedah www.hodedah.com support @hodedah.com STEP 1 CB SCREW M4 X 25MM PLASTIC DOWEL M8 X 25MM CB SCREW M4 X 35MM HANDLE 2838 (128MM) - PVC P/H SCREW M4 X 36MM 11 x 6pcs BOTTOM VIEW - Insert 34 x Plastic dowel (A) into Panels (1), (2), (3), (4), (5), (6), (7) & (8) using a plastic hammer.
- Page 6 Hodedah www.hodedah.com support @hodedah.com STEP 2 CB SCREW M3.5 X 12MM CB SCREW M4 X 35MM MINIFIX 5654 POWER NAIL " DRAWER SLIDE 16" BOTTOM VIEW BOTTOM VIEW - Slot 1 x Panel (14) into Panel (13) groove & use 14 x Power nail (F) for fix it. Knock by using a hammer.
-
Page 7: Right View
Hodedah www.hodedah.com support @hodedah.com STEP 3 CB SCREW M3.5 X 12MM CSK CAP M6 X 40MM ALLEN KEY DRAWER SLIDE 16" RIGHT VIEW LEFT VIEW LEFT VIEW RIGHT VIEW - Assemble 12 x Drawer slide (N1) to Panel (1), (7) & (8) with 3 x CB Screw M3.5 x 12m (B) using Philips head screwdriver. - Page 8 Hodedah www.hodedah.com support @hodedah.com STEP 4 CSK CAP M6 X 40MM CB SCREW M3.5 X 12MM ALLEN KEY PVC LEG STUD (L&R) PVC LEG STUD (SINGLE) MINIFIX 5654 ALLEN KEY - Attach Panel (8) and insert 4 x Csk Cap M6 x 40mm (E) & Cap (K). Tighten using Allen key (G).
-
Page 9: Job Complete
Hodedah Hodedah www.hodedah.com www.hodedah.com support @hodedah.com support @hodedah.com STEP 5 POWER NAIL " - Attach Panel (10) at the back of dressing table, use 52 x Power nail (F) for fix it. Knock by using a hammer. Job Complete !
