4.0 OPERATION

4.01 Front Control Panel

Overheating
Indicator
I
20C
"On / Off"
O
Switch
AC Power
Indicator
Air Vents
Work Lead
Connection
Art # A-04714
A. INDICATOR LAMP
• Power Indicator
power switch is turned on.
• TEMPERATURE Indicator
mally OFF. Indicator is ON when internal tem-
perature exceeds normal limits. Shut unit OFF;
let the unit cool before continuing operation.
• Air Error Indicator
and is accompanied by an intermittent audible
tone when there is not enough air pressure to
operate the power supply.
NOTE
It is possible to have enough air pressure to op-
erate the power supply but not enough air flow
to operate the torch.
• Torch Switch Latch Indicator
This indicator lights when the Torch Switch
Latch Button has been pressed for continuous
cutting.
Operation
Air Error Indicator
Torch Switch
Latch Indicator
14
Torch Switch
115VAC
230VAC A
Latch Button
Air Set
Button
Current
Control Knob
Torch
Connection
- Lights when primary
- Indicator is nor-
- This indicator lights
B. BUTTONS
• Torch Switch Latch Button
continuous cutting performance. Depress this
button ( turn "On" ) while cutting with the torch.
Release the torch trigger and the torch will con-
tinue to cut without depressing the torch trig-
ger.
• Air Set Button
to cool down heated torch.
C. MAIN CURRENT CONTROL KNOB
To adjust cutting current. Turning clockwise in-
creases the cutting current and counter clock-
wise decreases the cutting current.
Art # A-04428
D. PRIMARY POWER SWITCH, ON / OFF
The power switch is located on the front panel.
Placing the primary power switch to the "ON"
position energizes the power source.
When the power source is overloaded, the switch
turns to the OFF position automatically. DO
NOT TURN ON BY FORCE.
-
4-1
- For
- To check for air flow and
14
115VAC
A
230VAC
WARNING
Manual 0-4687
