Cabletron Systems 9F426-03 Appendix page 8

9F426-03 Module Specific Information
Ring Map Node Screen
The Ring Map Node Screen (Figure 2), displays specific information for a selected
FDDI node on the Ring Map.
Module Name: 9F426-03
Slot Number: 11
Address:
Upstream Address:
Node Class:
Mac Count:
Non-Master Count:
Master Count:
Peer Wrap:
Unattached Conc:
Twisted A-A:
Twisted B-B:
Synchronous Service:
Rooted:
6
SmartSwitch 9000 Local Management
Ring Map Node
SELECTED NODE
00:00:B8:00:10:62
NO UPSTREAM ADDRESS
NAS
0
0
0
No
No
No
No
No
No
EXIT
Figure 2. Ring Map Node Screen
Firmware Revision: 01.04.10
BOOTPROM Revision: 01.02.00
RETURN
