To unpack and install your Donut Robot®, follow the installation instructions in the Technical
Read this section completely before operating the machine!

Operating Controls

1. Ensure that the Donut Robot has been
connected to correct power source.
2. Ensure the fryer is filled with shortening.
If there is no shortening in the fryer, see
the section below, "Inserting Shortening".
3. Turn on the main circuit breaker on the
back of the heater head (
LIGHT will turn on).
4. Turn on the
2
(the temperature controller will turn on).
Belshaw Adamatic Bakery Group • www.belshaw-adamatic.com • 206-322-5474 •service@belshaw.com
6
Figure 1.2, Temperature controller
IMPORTANT
Supplement to this manual.
POWER
1
FRYER HEAT switch
MN-1032EN
CAUTION
5. Set the
CONTROL to the target frying
temperature (See Figure 1.2)
(TEMPERATURE CONTROL light
will turn on when fryer is heating).
6. Set
AUTO (the conveyor will start
automatically when the target
temperature is reached).
Donut Robot

Operation

TEMPERATURE
2
FRYER CONVEYOR switch to
3
®
