Other Controls - Haulotte HA12PX Operator's Manual

12 to 26m engine-powered articulated lifts
E
- Driving

3.2.4 - Other controls

• Switching from the lower console to the upper console :
The emergency stop push button ( P15 ) must be pulled.
• Turn the console activation selector ( P72 ) to the left to activate the upper console. The controls of the
lower console are de-activated.
• Switching from the upper console to the lower console :
The emergency stop push button ( P15 ) must be pulled.
• Turn the key of the console activation selector ( P72 ) to the right to activate the lower console. The
controls of the upper console are de-activated.
• Putting in transport position :
• Push the transport position selector ( P13 ) to the right to set the machine in transport position.
• Push the transport position selector ( P13 ) to the left to set the machine in operating position.
N.B.-:-T
HE RELEASE OF THE SELECTOR CAUSES ALL MOVEMENT TO STOP
• Engine rating acceleration :
• Turn the engine acceleration selector ( P21 ) to the right to switch to accelerated rating.
• Turn the engine acceleration selector ( P21 ) to the left to switch to idling speed.
N.B.-:-T
HE ACCELERATION OF THE ENGINE RATING ALLOWS INCREASING THE MOVEMENT SPEED FROM THE
LOWER CONSOLE
• For the machines equipped with beacon lights :
• Push the beacon light selector ( P24 ) to the right to switch on the beacon light.
• Push the beacon light selector ( P24 ) to the left to switch off the beacon light
