4.2 - OPERATIONAL TEST

Operational tests have proved the following facts :
• The machine has performed all movements without jerking, while carrying the nominal load.
• All safety systems are operating correctly.
• Maximum authorised operating speeds are not exceeded.

4.3 - STABILITY TEST

The stability test proves that the machine is stable in an unfavourable position. The moment
when the machine tips is calculated by combining loads in the most unfavorable position for
the machine (load W applied over distance L).
S t a b i l i t y
T (°)
Horizontal ( 1 )
-2,30 m (7 ft 6
in) x 0,80 m (2 5,5
ft 7 in) -45 km/
h (27,9 mph)
Horizontal ( 1 )
-1,20 m (3 ft
11 in) x 0,80 m
5,5
(2 ft 7 in) -60
km/h (37,2
mph)
24203 3237 0
t a b l e f o r H A 1 2 P X
W
Kilogramme
Pound (lb)
(kg)
826,7 375
859,8 390
E 09 07
( H A 3 3 J R T )
L
Feet inch (ft
Mètre (m)
in)
23-8 7,225
17-9 5,417
Moment of tipping over
Feet Pound Mètre Newton
(ft.lb) (mN)
1993,6 2703
1557,7 2112
EN 123
