Risk Of Jerks And Overturning - Haulotte HA12PX Operator's Manual

12 to 26m engine-powered articulated lifts
A
- Safety precautions

3.2.4 - Risk of jerks and overturning

On board the machine, respect the following instructions :
• Before engaging the machine on any internal or external surface (premises, bridge,
truck, etc.), check that the ground is capable of supporting the load. Check the
maximum value in the technical characteristics (
• During movement reversal from the upper or lower console, the joysticks or switches must be stopped
in the neutral position.
• According to the overall dimensions, place the loads in the centre of the platform or distribute them in
a uniform manner.
• On platforms, footpaths, etc. remain vigilant of the reversal of driving direction. Check the driving
direction with the help of the red or green arrow on the chassis and on the upper console.
• Make sure that the chassis is never closer than 1 m (3 ft 3 in) m to holes, bumps, steep slopes,
obstructions, debris and ground covering which may hide holes and other dangers.
• Do not drive the machine on slopes or tilts beyond limits. Check the maximum value in the technical
characteristics(
• Do not descend slopes at high speed.
• Do not raise the platform or drive with the platform raised on slopes or when the machine is tilted.
• Do not drive in reverse (direction opposite to the field of vision).
• Do not pull or push objects with the boom.
• Never use the machine in winds exceeding the authorized limit.
• Do not increase the surface area exposed to the wind. The greater the surface area exposed, the more
unstable the machine becomes.
N.B.-:-T
HE
RANGE AT
24203 3237 0
Section G 1- Main characteristics).
B
EAUFORT SCALE MEASURES THE WIND FORCE WITH A GRADUATION SYSTEM
10 (32 9 )
M FT IN ABOVE FLAT
E 09 07
Section G 1- Main characteristics).
,
CLEAR LAND IS ASSOCIATED WITH EACH DEGREE
. A
WIND SPEED
.
EN 15
