Upper Console Controls - Haulotte HA12PX Operator's Manual

12 to 26m engine-powered articulated lifts
E
- Driving

2.2.3 - Upper console controls

Refer to the corresponding operations to test the controls in the order mentioned
( Section E 3.3- Operations from the platform).
T e s t s f r o m
Step
1
2
3
4
5
6
T e s t s f r o m
Step
1
2
3
4
5
6
70 24203 3237 0
t h e u p p e r c o n s o l e
Engine start-up selector P61
Front axle direction selector ( P52 ) and movement joystick ( P52 )
Movements :
• Jib elevation/lowering ( P63 ) and movement joystick P52
• Platform rotation ( P64 ) and movement joystick P52
• Platform compensation ( P65 ) and movement joystick P52
• Arm elevation/lowering ( P66 ) and movement joystick P52
• Boom elevation/lowering ( P67 ) and movement joystick P52
• Boom telescope extention/retraction ( P68 ) and movement joystick P52
• Turntable rotation ( P69 ) and movement joystick P52
Driving speed selector :
• Slow speed selector ( P57 )
• Medium speed selector ( P58 )
• Fast speed selector ( P59 )
Differential blocking selector P60
Horn selector P62
t h e u p p e r c o n s o l e
Engine start-up selector P42
Driving P33
Platform rotation selector P38
Movements :
• Lifting/lowering of arm P50
• Lifting / lowering of boom P49
• Boom telescope extension/retraction P54
• Turntable rotation P49
• Platform compensation P40
Driving speed selector :
• Slow speed selector ( P71 )
• Medium speed selector ( P71 )
• Fast speed selector ( P71 )
Differential blocking selector P35
E 09 07
H A 1 2 P X
Control
and movement joystick P52
and movement joystick P52
and movement joystick P52
H A 1 6 X
Control
and movement joystick P33
and movement joystick P33
and movement joystick P33
( H A 3 3 J R T )
EN
