Movement Control - Haulotte HA12PX Operator's Manual

12 to 26m engine-powered articulated lifts
E
- Driving

3.2.3 - Movement control

L o w e r c o n s o l e
H A 1 6 S P X
H A 1 6 P X
( H A 6 1 J R T )
Control
Lifting/lowering of
arm
Lifting / lowering
of boom
Boom telescope
extension/
retraction
Lifting / lowering
of jib
Turntable rotation
76 24203 3237 0
c o n t r o l s
( H A 4 6 S J R T )
( H A 4 6 J R T ) -
- H A 2 6 0 P X
Push the arm elevation selector ( P12 ) upwards to raise the arm.
Push the arm elevation selector ( P12 ) downwards to lower the arm.
Push the boom lifting selector ( P10 ) upwards to lift the boom.
Push the boom lifting selector ( P10 ) downwards to lower the boom.
Push the boom telescoping selector ( P9 ) to the right to extend the
telescope.
Push the boom telescoping selector ( P9 ) to the right to retract the
telescope.
Push the jib selector ( P8 ) upwards to lift the jib.
Push the jib selector ( P8 ) downwards to lower the jib.
Push the turntable rotation selector ( P14 ) to the left for a clockwise
rotation.
Push the turntable rotation selector ( P14 ) to the right for an anti-
clockwise rotation.
H A 1 2 P X ( H A 3 3 J R T )
- H A 1 8 S P X
H A 1 8 P X ( H A 5 1 J R T )
( H A 8 0 J R T )
Action
E 09 07
-
( H A 5 1 S J R T )
- H A 2 0 P X
-
