Datatool S4 Series Training Manual page 55

Engineer Switch
number
Toggle to desired switch
Engineer Switch 1
Erase OTHER transmitter
codes
Engineer Switch 2
Resets software switches
to factory default settings
Engineer Switch 3
To recall the last 5 alarm
triggers
Engineer Switch 4
S4 Red & Green only
Movement sensor set up
Engineer Switch 5
Shock sensor adjustment
Engineer Switch 6
Arm/Disarm tones
Engineer Switch 7
Panic
Engineer Switch 8
Nudge sensor
Press both
buttons to
enter desired
To exit Engineer switches at any time turn Ignition switch off for at least 15 seconds
Switch
Press
Press
Number
of LED
flashes
1
2
3
Press
4
5
6
Number of LED Flashes = Degree setting (Default setting 3 Degrees)
Black button alters number of degrees the bike tilts to activate alarm. 2, 3, 4, 5
Press
Grey button & move machine to test, alarm beeps when movement detected
Number of LED Flashes = Sensitivity setting (Default setting level 8, Max 10)
Press
Press
Press
Number
of LED
flashes
1
2
3
Press
4
5
6
7
Method of altering setting and accepting
Both buttons (A double beep will be heard) to erase all transmitters
except for the one being used
Press Both buttons to save and exit back to switch selection
Both buttons (A double beep will be heard) to confirm
all software switches have been reset to factory default settings
Press Both buttons to save and exit back to switch selection
Number of LED Flashes = Cause of trigger
Last trigger shown first. Pressing the Grey button to take you back
through previous triggers. Press the Black button to erase the memory
Loss of main power or earths (Fuse blown, Wires cut, etc)
Machine 'hot-wired' (Ignition turned on)
Movement trigger - The machine has been moved (S4 Red and Green
only)
Nudge trigger (The machine has been knocked repeatedly)
(Please note: On S4 Red and Green this only works if the nudge sensor is
set to 'fully active')
Trigger circuit 1 has been activated (Alarm protection switch)
Trigger circuit 2 has been activated (Side stand, Accessory loop, etc) - S4
Red and Green only
Press Both buttons to save and exit back to switch selection
Press Both buttons to save and exit back to switch selection
Grey button = Increase sensitivity to Impacts
Black button = Decrease sensitivity to Impacts
Impact setting can be tested by nudging the machine
Press Both buttons to save and exit back to switch selection
Grey button = Tones ON (LED ON)
Black button = Tones OFF (LED OFF) (Default setting)
Press Both buttons to save and exit back to switch selection
Grey button = Panic ON (LED ON) (Default setting)
Black button = Panic OFF (LED OFF)
Press Both buttons to save and exit back to switch selection
Number of LED Flashes = Warn-away setting
(Default setting 2 LED flashes)
Instant Trigger – Triggers on first impact/movement detection
1 Warn-away beep and trigger on second impact within 2 minutes
2 Warn-away beeps and trigger on third impact within 2 minutes
3 Warn-away beeps and trigger on fourth impact within 2 minutes
4 Warn away beeps and trigger on fifth impact within 2 minutes
Permanent warn – away. The alarm will beep to warn off but will not
trigger the alarm into a full reaction (S4 Red and Green only)
No Reaction. The shock sensor is turned OFF (S4 Red and Green only)
Press Both buttons to save and exit back to switch selection
Annex 3
