Engineer's software switch table
The factory default settings are in bold text.
No. Feature
1 Erase OTHER transmitter codes
(except code of transmitter being used)
2 Return Software Switches to Default
3 System Diagnostics with Event Memory
4 Movement Sensor Adjustment
5 Nudge Sensor Adjustment
6 Arm / Disarm Tones
7 Panic
8 Nudge sensor
Please note: The inclusion of arm and disarm indication beeps is strictly forbidden in all EU countries.
Engineer's software switches
The next pages give detailed information on each of the engineer switches above, how to use them and the effect any
changes will have on the alarm.
Transmitter erase (Engineer switch 1)
This software switch is to remove transmitters which have been previously been coded into the system but are no longer
in the possession of the rightful owner of the machine either due to loss, theft or transfer of ownership. This ensures the
security of the system.
Each time the system is disarmed the LED on the machine flashes to indicate the number of transmitters already coded
into the system (up to a maximum of 6 in total).
Through this the owner or engineer will always know they are in possession of ALL valid transmitters.
When this software switch is used it deletes all transmitters from the memory of the system with the exception of the
transmitter being used to execute the deletion.
Any S4 series transmitters which are to be used must be re-coded in using the transmitter learning procedure described in
the owner's manual. This can be done either by the engineer or the customer but it is advisable for the engineer to do this
as the customer may forget.
For this reason the customer should be requested to provide all the S4 remotes as part of this process. If they do not they
should be advised it is important they carry out the re-code at the earliest opportunity.
To delete all other remote controls
•
Move to switch 1 by using the Grey or Black button (1 lower tone beep will be heard)
•
Press both buttons of the remote to enter switch 1, a double beep will be heard and all remote controls other
than the one pressed to enter the switch will have been deleted.
•
Press any button of the remaining remote control to exit switch 1 and move directly to switch 2
Settings available
This switch removes all remotes except the one being used to carry out
the process. Any remotes required to operate the system MUST be re-
coded after carrying out this function
This setting returns ALL software switches to the factory defaults
(including customer set switches)
Gives last five trigger types in reverse order
0 0
4 settings 2 , 3 , 4
10 settings (Default setting level 8)
Trigger on first nudge detection
1 Warn-away and trigger on second nudge
2 Warn-aways and trigger on third nudge
3 Warn-aways and trigger on fourth nudge
4 Warn-aways and trigger on fifth nudge
Continuous warn away with no trigger (S4 Red and Green only)
Nudge sensor Off (S4 Red and Green only)
37
0 0
, 5 (S4 Red and Green Only)
On/ Off
On/Off
