- Page 1 FARGO® DTC®ii Plus User Guide PLT-05151, A.0.R August 2020 Powering Trusted Identities...
-
Page 2: What's New
Trademarks HID GLOBAL, HID, the HID Brick logo, DTC, FARGO and iCLASS are trademarks or registered trademarks of HID Global, ASSA ABLOY AB, or its affiliate(s) in the US and other countries and may not be used without permission. All other trademarks, service marks, and product or service names are trademarks or registered trademarks of their respective owners. -
Page 3: Specifications
Section 01 Specifications Powering Trusted Identities... -
Page 4: Regulatory Compliance
Powering FARGO® DTC®ii Plus Trusted Identities User Guide 1.1 Introduction The purpose of this section is to provide you with specific information on the Regulatory Compliances, Agency Listings, Technical Specifications and Functional Specifications for the DTC®ii Plus card printer. 1.2 Regulatory compliance The card printer is listed under UL 60950-1 (2nd edition) Information Technology Equipment File Number: E145118 This product is intended to be supplied by a Listed Power Unit marked Class 2 and rated for 24Vdc, 3.3A minimum. - Page 5 Powering FARGO® DTC®ii Plus Trusted Identities User Guide 1.2.2 United States This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
-
Page 6: Safety Messages - United States
Powering FARGO® DTC®ii Plus Trusted Identities User Guide 1.3 Safety messages 1.3.1 Safety messages - United States Symbol Critical instructions for safety purposes Danger: Failure to follow these guidelines results in personal injury or death. To prevent personal injury or death: Reference the following safety messages before performing an operation. -
Page 7: Safety Messages - French
Powering FARGO® DTC®ii Plus Trusted Identities User Guide 1.3.2 Safety messages - French Symbole Instructions critiques visant la Sécurité Danger: Si ces directives ne sont pas suivies les résultats peuvent être des lésions corporelles ou la mort. Pour éviter des lésions corporelles ou la mort: Rapportez-vous aux avis suivants de sécurité... -
Page 8: Technical Specifications
Powering FARGO® DTC®ii Plus Trusted Identities User Guide 1.4 Technical specifications Term Function Print Method Dye Sublimation / Resin Thermal Transfer Print resolution 300 dpi (11.8 dots/mm); continuous tone Colors Up to 16.7 million colors / 256 shades per pixel Print Ribbon Options Full-color with resin black and overlay panel, YMCKO* (500 prints) Full-color half-panel with resin black and overlay panel, YMCKO* (850 prints) -
Page 9: Functional Specifications
Powering FARGO® DTC®ii Plus Trusted Identities User Guide Term Function Output Hopper Card 100 cards (.030”/.762.mm) Capacity Reject Hopper Card 100 cards (.030”/.762.mm) Capacity Card Cleaning Card cleaning roller integrated into the ribbon cartridge. A new cleaning roller is included with each ribbon cartridge. Printer Memory 32MB RAM Operating Systems... - Page 10 Powering FARGO® DTC®ii Plus Trusted Identities User Guide = Dye-Sublimation Magenta Panel = Dye-Sublimation Cyan Panel = Resin Black Panel (Premium unless otherwise stated) = Clear Protective Overlay Panel = Fluorescing Panel PLT-05151, A.0.R August 2020...
-
Page 11: Ribbon Types And Print Counts
Powering FARGO® DTC®ii Plus Trusted Identities User Guide 1.6.1 Ribbon types and print counts Ribbon DTCii YMCKO – Full Color/Resin Black / Overlay YMCKO Half Panel – Full Color (1/2) / Resin Black/Overlay YMCFKO - Full Color/UV Fluorescing / Resin Black / Overlay YMCKK - Full Color / 2 Resin Black YMCKOK - Full Color / 2 Resin Black / Overlay YMCFKOK - Full Color/UV Fluorescing / 2 Resin Black / Overlay... -
Page 12: Printer Components: Blank Cards
Certain types of smart card chips are raised slightly above the cards surface which also results in poor color transfer. UltraCard Brand Cards The UltraCard product line, available exclusively as part of HID Global FARGO brand secure card issuance solutions, has a long standing reputation among dealers and end-Users for consistent quality in construction. -
Page 13: Revision History
Powering FARGO® DTC®ii Plus Trusted Identities User Guide Revision history Date Description Revision August 2020 Initial release. A.0.R PLT-05151, A.0.R August 2020... - Page 14 Powering Trusted Identities PLT-05151, A.0.R Americas & Corporate Asia Pacific Europe, Middle East & Africa Brazil 611 Center Ridge Drive 19/F 625 King's Road North 3 Cae Gwyrdd Condomínio Business Center Av. Austin, TX 78758 Point Green Meadow Springs Ermano Marchetti, 1435 Galpão A2 Island East Hong Cardiff, CF15 7AB United - CEP 05038-001...
