Remote Registration - Lightspeed TOPCAT Registration Manual

TOPCAT ACCESS REGISTRATION GUIDE

REMOTE REGISTRATION

ADDING OR REPLACING A REMOTE CONTROL
1. Start with the Topcat plugged in and powered on. To verify it is powered on, there will
be a blue power light on the front of the Topcat.
2. Use the existing Flexmike to register the Remote Control. Ensure that the Flexmike is
powered on and linked to the Topcat.
3. Open the Flexmike battery compartment and pull the battery out (leaving it plugged in) to reveal the registration
button.
4. Using a paperclip with the end straightened out, press and hold for 3 seconds the registration button inside the
Flexmike. The 1 and 2 lights will begin blinking on the Topcat Access.
5. Briefly press the registration button on back of the remote.
6. The registration light on the remote will turn on for about 1 second, then turn off. The #2 light on the
Topcat will also turn off.
7. The registration is complete.
8. If there is a second remote, repeat steps 2-5, paying attention to the teacher select switch.
9. If desired, you can pair the remote with your Apple iOS device -
User Manual for device compatibility).
10. Visit the App Store to search for and download "Lightspeed Flexcat Remote".
11. Once you open the app, you will be prompted to pair with your remote.
12. Using a paperclip with the end straighted out, insert it into the "BT" button on the side of the
remote. The Mute button will begin blinking to indicate the remote is in pairing mode.
13. The app will then prompt you to "Pair" with the remote. Press the pair button to complete the
process. the app will take you through a tutorial on how to use the vaious functions.
14. When using the app, we recommend always leaving the remote control on the charger when not
in use. It must stay powered on and charged in order for the app to work.
15. The remote does remain fully operational and can be used in place of the app at any time.
NOTE: If there are two microphones, one remote should be set to Teacher 1, the 2nd to Teacher 2, ensuring the remote
label matches the Teacher 1 or Teacher 2 designation.
16. Once the remote is registered, you may now use it to initiate registration of additional or replacement pods and
microphones.
17. Place system ID number (attached to the Topcat Quickstart Guide) on the new Remote Control.
NOTE: if at any point, the Topcat or remote lights begin blinking rapidly, that indicates a registration error. Power off
the remote, then repeat steps 4-6.
Registration
Button
iPhone , iPad , or iPod touch
® ®
. (See
®
Apply to system components to indicate which parts are registered
as a system. Keep registered items together when storing away.
334-0162-02-00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
00-01
RETAIN EXTRA LABELS IN THE EVENT A COMPONENT IS REPLACED OR ADDED.
Solid light
Blinking lights
REG
1
4 2
3
5 6
UP DN
Mute Vol
Vol
Registration ID Labels
10101
00-01 00-01 00-01
00-01 00-01 00-01
00-01 00-01 00-01
00-01 00-01 00-01
00-01 00-01 00-01
00-01 00-01 00-01
