Nidec Commander C200 Power Installation Manual page 91

Table 5-11 2 % line reactors
Voltage
Drive
Line reactor
rating
model
designation
number
V
05200250 200
06200330 200
06200440 200
05400270 400
05400300 400
06400350 400
06400420 400
06400470 400
05500030 575
05500040 575
05500069 575
06500100 575
06500150 575
06500190 575
06500230 575
06500290 575
06500350 575
5.1.7 Motor requirements
No. of phases: 3
Maximum voltage:
200 V drive: 240 V
400 V drive: 480 V
575 V drive: 575 V
5.1.8 Storage
-40 °C (-40 °F) to +55 °C (131 °F) for long term storage, or to +70 °C (158 °F) for short term storage.
Storage time is 2 years.
Electrolytic capacitors in any electronic product have a storage period after which they require
reforming or replacing.
The DC bus capacitors have a storage period of 10 years.
The low voltage capacitors on the control supplies typically have a storage period of 2 years and are
thus the limiting factor.
Low voltage capacitors cannot be reformed due to their location in the circuit and thus may require
replacing if the drive is stored for a period of 2 years or greater without power being applied.
It is therefore recommended that drives are powered up for a minimum of 1 hour after every 2 years
of storage. This process allows the drive to be stored for a further 2 years.
Unidrive M/HS Frame 5 to 6 Power Installation Guide
Issue Number: 8
CT Part
number
INL2008 4401-0226
INL2004 4401-0146
INL2005 4401-0147
INL4013 4401-0236
INL4013 4401-0236
INL4006 4401-0154
INL4007 4401-0155
INL4008 4401-0156
INL5007 4401-0242
INL5008 4401-0243
INL5009 4401-0244
INL5001 4401-0157
INL5002 4401-0158
INL5003 4401-0159
INL5004 4401-0160
INL5005 4401-0161
INL5006 4401-0223
Line
reactor
Inductance Weight
current
rating
A mH
32 0.26
48.8 0.17
56.6 0.15
32 0.48
32 0.48
36.5 0.4
46.2 0.32
60.6 0.24
4.3 4.92
6.8 3.11
11.4 1.89
13.2 1.6
18.7 1.13
24.3 0.87
29.4 0.72
37.1 0.57
47 0.48
Length Width
kg mm mm
3.30 156 60
4.8 156 75
4.9 156 120
4.9 156 75
4.9 156 75
8 206 140
9 206 140
11 255 125
1.4 80 75
1.8 156 70
3.2 156 60
3.5 156 60
4.9 156 75
6 206 95
7.4 206 130
11 230 130
12.5 230 130
Height
mm
145
145
130
145
145
200
200
195
130
125
145
145
145
200
200
210
210
