2.3

Nameplate description

Figure 2-2 Typical drive rating labels (Unidrive M600 labels illustrated)
Refer to
User Guide
Heavy Duty /
Normal Duty
power rating
Input voltage
Output
voltage
Approvals
Date code format
NOTE
The date code is four numbers. The first two numbers indicate the year and the
remaining numbers indicate the week of the year in which the drive was built.
Example:
A date code of 1710 would correspond to week 10 of year 2017.
16
Model
M600-032 00050 A
Input
Date code
frequency
1710
No.of phases &
Typical input current for
Normal Duty rating
Heavy Duty /
Normal Duty rating
output current
Serial
number
Heavy Duty
Frame
current rating
size
Voltage
Drive format
CE approval
RCM regulatory
compliance mark
UL / cUL approval
RoHS compliant
Functional safety
Eurasian conformity
Unidrive M/HS Frame 5 to 6 Power Installation Guide
Key to approvals
Europe
Australia
USA & Canada
Europe
USA & Canada
Eurasia
Issue Number: 8
