Nidec Commander C200 Power Installation Manual page 68

Table 4-10 Drive and EMC filter cross reference
200 V
05200250
06200330 to 06200440
400 V
05400270 to 05400300
06400350 to 06400470
575 V
05500030 to 05500069
06500100 to 06500350
High ground leakage current
When an EMC filter is used, a permanent fixed ground connection must be provided which
does not pass through a connector or flexible power cord. This includes the internal EMC
filter.
WARNING
The installer of the drive is respons ble for ensuring compliance with the EMC regulations
NOTE
that apply in the country in which the drive is to be used.
4.12.1 Grounding hardware
The drive is supplied with a grounding bracket and grounding clamp to facilitate EMC compliance.
They provide a convenient method for direct grounding of cable shields without the use of "pig-tails".
Cable shields can be bared and clamped to the grounding bracket using metal clips or clamps
supplied) or cable ties. Note that the shield must in all cases be continued through the clamp to the
intended terminal on the drive, in accordance with the connection details for the specific signal.
1
A suitable clamp is the Phoenix DIN rail mounted SK14 cable clamp (for cables with a maximum
outer diameter of 14 mm).
• See Figure 4-9 and Figure 4-10 for details on installing the grounding clamp.
• See Figure 4-11 for details on installing the grounding bracket.
68
Model CT part number
Unidrive M/HS Frame 5 to 6 Power Installation Guide
4200-0312
4200-2300
4200-0402
4200-4800
4200-0122
4200-3690
Issue Number: 8
