Controller
Note!
Confirm the elimination of the fault by pressing "Quit" at the controller
operator panel. All other alarms are automatically reset as soon as the
cause has been eliminated.
ER Code
Alarm
01
Min. pressure
06
Make-up time
07
Make-up cycles
08
Pressure measurement
10
Maximum pressure
11
Make-up volume
12
Filling time
13
Filling volume
15
Make-up valve
16
Power failure
19
Stop > 4 h
20
Max. make-up volume
21
Maintenance recommended
24
Softening
30
I/O module fault
12 — English
Group
Causes
message
YES
The set value for the "P
working pressure has been
exceeded.
•
Water loss in the system.
•
Expansion vessel defective.
Set time for the make-up time has
been exceeded.
•
Severe water loss in the
system.
•
Make-up line not connected.
•
Make-up rate insufficient.
•
Make-up hysteresis too high.
Set value for the make-up cycles has
been exceeded.
•
Leakage in the system.
YES
Controller receives incorrect signal.
•
Pressure transducer plug not
plugged in.
•
Broken wire from "PIS"
pressure transducer.
•
"PIS" pressure transducer
defective.
Set value for the maximum pressure
has been exceeded.
•
Safety valve defective.
•
Insufficient dimensioning of
the pipeline to the system.
Set value of the water meter has
been exceeded.
•
Leakage in the system.
•
Water volume per contact
incorrectly set in the Service
menu.
Set value for the maximum filling
time has been exceeded.
•
System volume too large
(≤ 3000Liter).
•
System volume too large
(≤ 3000Liter).
•
Water volume per contact
incorrectly set in the Service
menu.
Make-up without demand
•
"WV" make-up valve leaking
No power.
The device is in Stop mode for more
than 4 hours.
Set value for the make-up quantity
has been exceeded.
Set value exceeded.
•
Set value for the water
capacity has been reached.
•
Time interval for replacement
of the softening cartridge has
been reached.
•
I/O module defective.
•
Connection between option
card and controller faulty.
•
Option card defective.
Fillcontrol Plus — 19.10.2020 - Rev. C
Note!
Group messages are issued via a floating contact which is set in the
Customer menu, see chapter 9.2 "Configuring settings in the controller"
on page 10 .
Remedy
" minimum
•
Check the system for leaks.
0
•
Replace the expansion vessel.
•
Check the function in manual
mode.
•
Check the system for leaks.
•
Connect the make-up system.
•
Check the make-up rate.
•
Check the make-up hysteresis.
•
Check the system for leaks.
•
Plug in the plug.
•
Replace the wire.
•
Replace the "PIS" pressure
transducer.
•
Check the actuating pressure of the
safety valve.
•
Replace the safety valve.
•
Increase the diameter of the
pipeline to the system.
•
Check the system for leaks.
•
Check the set value.
•
Restart the filling process
•
If necessary, restart the filling
process
•
Set the water quantity per contact
in the Service menu.
•
Replace the "WV" make-up valve
Check power supply.
Select Automatic mode.
Reset the "Make-up volume" meter in the
Customer menu.
Carry out maintenance.
Replace the softening cartridge.
Inform Reflex Customer Service.
Alarm reset
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
–
–
"Quit"
"Quit"
"Quit"
