Customer Menu; Service Menu; Messages - Reflex Fillcontrol Plus Operating Manual

Indication on the Meaning
display
Disable make-up? This value is only displayed if "YES" has been set in the
"With softening" menu option.
YES
• YES: The system stops the make-up process when
the set soft water capacity is exceeded.
• NO: The system does not stop the make-up
process. The system displays the "Softening"
message.
Hardness reduction This value is only displayed if "YES" has been set in the
"With softening" menu option.
10 °dH
• Hardness reduction is calculated from the
difference of the overall water hardness GH
and the target water hardness GH
Hardness reduction = GH
Enter the value in the controller. Consult the
manufacturer information for third-party products.
Cap. soft water This value is only displayed if "YES" has been set in the
"With softening" menu option.
05000 l
The attainable soft water capacity is calculated from the
type of softening used and the specified hardness
reduction.
• Fillsoft I, soft water capacity ≤ 6000/hardness red. l
• Fillsoft II, soft water capacity ≤ 12000/hardness
red. l
Enter the value in the controller. Consult the
manufacturer information for the values of third-party
products.
Remaining cap. soft This value is only displayed if "YES" has been set in the
w. "With softening" menu option.
000020 l • Available soft water capacity.
Replacement This value is only displayed if "YES" has been set in the
"With softening" menu option.
18 months
• Manufacturer specification for the replacement
interval of the softening cartridges, regardless of
the calculated soft water capacity. The system
displays the "Softening" message.
Next maintenance Recommended maintenance messages.
012 months • Off: Without maintenance recommendation.
• 001 – 060: Maintenance recommendation in
months.
Floating fault For the output of messages to the floating contact, see
contact chapter 9.3 "Messages" on page 11 .
YES • YES: Output of all messages.
NO: Output of all messages identified with "xxx"
•
("01", for example).
Switch to the "Fault memory" sub-menu.
Fault memory˃
• Press "OK" to open the menu.
• Use the "▼▲" buttons to open the sub-menu.
ER 01...xx The last 20 alarms are stored with fault type, date, time,
and fault code.
See the chapter "Messages" for more information about
the ER... messages.
Parameter Switch to the "Parameter memory" sub-menu.
memory˃
• Press "OK" to open the menu.
• Use the "▼▲" buttons to open the sub-menu.
P0 = xx.x bar The last 10 entries of the minimum working pressure are
stored with date and time.
Date | Time
V0.60 Information about the software version
actual
.
target
-GH l °dH
actual target
Fillcontrol Plus — 19.10.2020 - Rev. C
9.2.1

Customer menu

The device controller is shipped with the following default settings. Use the
Customer menu to adjust these values to local conditions. In special cases, it is
possible to further adjust the values in the Service menu.
Parameter Setting
Language EN
Fillcontrol XX Magcontrol
Minimum operating 1.5 bar
pressure P
0
Safety valve, pressure 3.0 bar
Next maintenance 12 months
Volt-free contact NO
Make-up
Maximum make-up volume 5000 litres
Maximum make-up time 20 minutes
Maximum make-up cycles 3 cycles
within 2
hours
Softening (Only if "With softening yes")
Shut off make-up NO
Hardness reduction 8°dH
Maximum make-up volume 0 litres
Soft water capacity 0 litres
Cartridge replacement 18 months
9.2.2

Service menu

This menu is protected with a password. It can be accessed only by the Reflex
Customer Service. A partial summary of the settings stored in the Service menu is
proved in the Chapter Default settings.
Service menu
Parameter Setting
Makeup
Pressure differential, 0.2 bar
"NSP" makeup
Pressure differential, 0.3 bar
filling pressure PF – P
0
Water quantity for each 10 l / K
contact
Maximum filling OFF
contacts
9.3

Messages

Messages with ER codes are displayed at the controller.
• Use the arrow keys at the controller operating panel to select the
messages.
• By selecting the "Fault memory" main menu in the Customer menu, you
display the last 20 alarms.
• Alarm causes can be eliminated by the operator or a specialist workshop.
• If required, please contact the Reflex Customer Service.
Controller
Comment
Display language
For systems with diaphragm-type
expansion vessel
Only Magcontrol
see chapter 7.2 "Determining the P
0
minimum operating pressure for
the controller" on page 8
Tripping pressure for the safety
valve at the heat generator in the
system
Time left to the next due
maintenance
Only the messages marked in the
"Messages" list
Only if controller with "With water
meter yes"
Magcontrol
Magcontrol
In the event of soft water residual
capacity = 0
= Setpoint – Actual
Attainable make-up quantity
Attainable water capacity
Replace cartridge
Remarks
Only Magcontrol
Only Magcontrol
Only if a water meter is
installed.
Limits the filling volume.
Only if a water meter is
installed.
English — 11
