Controller
Service menu
Parameter Setting
Pressurisation
Compressor "ON" P + 0.3 bar
0
Compressor "OFF" P + 0.4 bar
0
"Compressor run time 240 minutes
exceeded" message
Overflow line "CLOSED" P + 0.4 bar
0
Overflow line "OPEN" P + 0.5 bar
0
Maximum pressure P + 3 bar
0
ER Alarm
Code
01 Minimum pressure
02.1 Insufficient water
03 High water
04.1 Compressor
05 Compressor run time
06 Make-up time
07 Make-up cycles
08 Pressure measurement
09 Level sensor
10 Maximum pressure
14 — English
Comment
Differential pressured added to
the "P " minimum operating
0
pressure.
Differential pressured added to
the "P " minimum operating
0
pressure.
The message is displayed after
the compressor runs for 240
minutes.
Differential pressured added to
the "P " minimum operating
0
pressure.
Differential pressured added to
the "P " minimum operating
0
pressure.
Differential pressured added to
the "P " minimum operating
0
pressure.
Floating Causes
contact
YES • Set value not reached.
• Water loss in the system.
• Compressor fault.
• Controller in Manual mode.
- • Set value not reached.
• Make-up disabled.
• Air in the system.
• Dirt trap clogged.
YES • Set value exceeded.
• Make-up disabled.
• Water intake through a leak in a thermal
transfer medium of the user.
• Vessel too small.
YES • Compressor disabled.
• Fuse defective.
- • Set value exceeded.
• Severe water loss in the system.
• Air lines leaking.
• Solenoid valve in the overflow line does not
close.
- • Set value exceeded.
• Water loss in the system.
• Make-up line not connected.
• Make-up rate insufficient.
• Make-up hysteresis too low.
- Set value exceeded.
YES Controller receives incorrect signal.
YES Controller receives incorrect signal.
- • Set value exceeded.
• Pressure relief pipe not functioning.
• Dirt trap clogged.
Reflexomat Silent Compact — 16.10.2020 - Rev. A
Parameter Setting
Filling levels
Insufficient water "ON" 5 %
Insufficient water "OFF" 12 %
Solenoid valve in overflow 90 %
line "CLOSED"
9.2.2

Messages

The display provides alarms in plain text and the ER codes shown in the list. Use
the arrow buttons to scroll through multiple alarms displayed at the same time.
The fault memory stores the last 20 alarms for review, see chapter 9.2
"Configuring settings in the controller" on page 12 .
Alarm causes can be eliminated by the operator or a specialist workshop. If this is
not possible, contact the Reflex Customer Service.
 Note!
Clearing of the cause must be confirmed by pressing the "Ack" button on
the operator panel. All other alarms are automatically reset as soon as
the cause has been eliminated.
 Note!
Floating contacts, setting in the Customer menu, see chapter 9.2
"Configuring settings in the controller" on page 12 .
• Check set value in the Customer or Service menu.
• Check water level.
• Check compressor.
• Set the controller to Automatic mode.
• Check set value in the Customer or Service menu.
• Clean the dirt trap.
• Check functioning of the "PV1" solenoid valve.
• If necessary, manually add water.
• Check set value in the Customer or Service menu.
• Check functioning of the "WV1" solenoid valve.
• Drain water from the "VG" vessel.
• Check site heat transfer medium for leaks.
• Check set values in the Customer or Service menu.
• Replace the fuse.
• Check set value in the Customer or Service menu.
• Check the water loss and correct, if necessary.
• Seal any leak in the air system.
• Check functioning of the "PV1" solenoid valve.
• Check set value in the Customer or Service menu.
• Check water level.
• Connect make-up pipe
• Check set value in the Customer or Service menu.
• Seal any leak in the system.
• Connect the plug.
• Check functioning of the pressure sensor.
• Check the cable for damage.
• Check the pressure sensor.
• Check functioning of the load cell.
• Check the cable for damage.
• Connect the plug.
• Check set value in the Customer or Service menu.
• Check functioning of the pressure relief pipe.
• Clean the dirt trap.
Comment
Remedy Alarm
reset
"Quit"
-
-
"Quit"
-
"Quit"
"Quit"
"Quit"
"Quit"
"Quit"
