Commissioning
7.2

Reflexomat switching points

The "P " minimum operating pressure is determined by the location of the
0
pressurisation. The controller calculates the switching points for the "PV"
solenoid valve and the "CO" compressor from the "P
pressure.
The "P " minimum operating pressure is calculated as follows:
0
P = P + P + 0.2 bar* Enter the calculated value in the start routine
0 st D
of the controller, see chapter 7.3 "Modifying
the controller's start routine" on page 10 .
P = h /10 h
st st st
P = 0.0 bar for safety temperatures ≤ 100 °C
D
P = 0.5 bar for safety temperatures = 110 °C
D
*Addition of 0.2 bar recommended, no addition in extreme cases
 Note!
Avoid dropping below the "P
vaporisation and cavitation are thus excluded.
7.3

Modifying the controller's start routine

 Note!
During commissioning, you must once execute the start routine.
• For information about controller operation, see chapter 9.1
"Operator panel" on page 12 .
The start routine is used to set the required parameters for the device
commissioning. It commences with the first activation of the controller and can
be run only once. Parameter changes or checks are possible after the start
routine in the customer menu is exited, see chapter 9.2 "Configuring settings in
the controller" on page 12 .
 Note!
Plug in the contact plug to provide power (230 V) to the controller.
You are now in Stop mode. The "Auto" LED on the operator panel has
extinguished.
10 — English
" minimum operating
0
in metres
"minimum operating pressure. Vacuum,
0
Reflexomat Silent Compact — 16.10.2020 - Rev. A
Indication on the
Meaning
display
Reflexomat Device name
Language Standard software in various languages.
Read the Prior to commissioning, read the entire operating manual
operating manual and verify the proper assembly.
Min. op. pressure Enter the value for the minimum operating pressure.
• Calculation of the minimum operating pressure, see
chapter 7.2 "Reflexomat switching points" on
page 10 .
Time Change the flashing display items for "Hour", "Minute",
and "Seconds" to the current time.
• The time of an alarm will be stored in the fault
memory.
Date Change the flashing display items for "Day", "Month", and
"Year" to the current date.
• The date of an alarm will be stored in the fault
memory.
00500 l / 740 mm Select the size of the "VG" primary vessel.
GB = 0093 kg • For the primary vessel data, see the type plate or, see
chapter 5 "Technical data" on page 5 .
1 % / 1.7 bar Null balancing of the level sensor.
Null balancing! • The controller checks whether the level measuring
signal matches the dimensional data of the "VG"
primary vessel. The primary vessel must be fully
emptied,
sensor" on page 7 .
0 % / 1.0 bar Upon successful conclusion of the null balancing, confirm
with "OK" on the controller operator panel.
Null balancing
concluded
successfully!
Cancel null Select "Yes" or "No" on the controller display and confirm
balancing? with "OK" on the controller operator panel.
No • Yes: The "VG" primary vessel is fully emptied and the
device is installed as per the instructions.
– Null balancing is still not possible, confirm with
"Yes". The start routine is terminated. Use the
customer menu to repeat the null balancing,
see chapter 9.2 "Configuring settings in the
controller" on page 12 .
– Contact Reflex Customer Service, see
chapter 12.1 "Reflex Customer Service" on
page 17 .
• No: The start routine restarts.
– Check the prerequisites for the commissioning,
see chapter 7.1 "Checking the requirements for
commissioning" on page 9 .
Terminate This message appears on the display only after null
routine? balancing has been successful.
No Select "Yes" or "No" on the controller display and confirm
with "OK" on the controller operator panel.
• Yes: The start routine is terminated, the device
automatically switches to Stop mode.
• No: The start routine restarts.
0 % / 2.0 bar The level indication is at 0 %.
STOP

Note!
After successful conclusion of the start routine, you are in Stop mode. Do
not yet switch to Automatic mode.
see, see chapter 6.3.3 "Fitting the level
