Default Settings - Reflex Reflexomat Silent Compact Operating Manual

Indication on the Meaning
display
With water meter. • YES: FQIRA+ contact water meter is installed, see
chapter 4.6 "Optional equipment and accessories"
YES
on page 5 .
This is the prerequisite for the make-up volume
monitoring and the operation of a softening
system.
• NO: A contact water meter is not installed
(standard model).
Only displayed if "YES" has been set in the "With water
Make-up volume
meter" menu option.
000020 l
• Use "OK" to delete the counter.
– Press "YES" to reset the value displayed to
"0".
– Press "NO" to retain the displayed value.
Max. make-up This value is only displayed if "YES" has been set in the
volume "With water meter" menu option.
000100 l • When the set volume is exceeded, the system
interrupts the make-up process and returns the
error message "Max. make-up volume exceeded".
This value is only displayed if "YES" has been set in the
With softening
"With water meter" menu option.
YES
• YES: Further queries follow about softening.
• NEIN: The system does not offer more queries
regarding the softening process.
This value is only displayed if "YES" has been set in the
Disable make-up?
"With softening" menu option.
YES
• YES: The system stops the make-up process when
the set soft water capacity is exceeded.
• NEIN: The system does not stop the make-up
process. The system displays the "Softening"
message.
Hardness reduction This value is only displayed if "YES" has been set in the
"With softening" menu option.
10 °dH
• Hardness reduction is calculated from the
difference of the overall water hardness GH
and the target water hardness GH
Hardness reduction = GH
Enter the value in the controller. Consult the
manufacturer information for third-party products.
Cap. soft water This value is only displayed if "YES" has been set in the
"With softening" menu option.
05000 l
The attainable soft water capacity is calculated from the
type of softening used and the specified hardness
reduction.
• Fillsoft I, soft water capacity ≤ 6000/hardness red. l
• Fillsoft II, soft water capacity ≤ 12000/hardness
red. l
Enter the value in the controller. Consult the
manufacturer information for the values of third-party
products.
Remaining cap. soft This value is only displayed if "YES" has been set in the
w. "With softening" menu option.
000020 l • Available soft water capacity.
Replacement This value is only displayed if "YES" has been set in the
"With softening" menu option.
18 months
• Manufacturer specification for the replacement
interval of the softening cartridges, regardless of
the calculated soft water capacity. The system
displays the "Softening" message.
Next maintenance Recommended maintenance messages.
012 months • Off: Without maintenance recommendation.
• 001 – 060: Maintenance recommendation in
months.
actual
.
target
-GH l °dH
actual target
Reflexomat Silent Compact — 16.10.2020 - Rev. A
Indication on the Meaning
display
Floating fault For the output of messages to the floating contact, see
contact chapter 9.2.2 "Messages" on page 14 .
YES • YES: Output of all messages.
NEIN: Output of all messages identified with "xxx"
•
("01", for example).
Fault memory˃ Switch to the "Fault memory" sub-menu.
• Press "OK" to open the menu.
• Use the "▼▲" buttons to open the sub-menu.
ER 01...xx The last 20 alarms are stored with fault type, date, time,
and fault code.
See the chapter "Messages" for more information about
the ER... messages.
Parameter Switch to the "Parameter memory" sub-menu.
memory˃
• Press "OK" to open the menu.
• Use the "▼▲" buttons to open the sub-menu.
P0 = xx.x bar The last 10 entries of the minimum working pressure are
stored with date and time.
Date | Time
Vessel info The system displays the values for the volume and the
diameter of the "RG" primary vessel.
00500 l
• If you identify differences to the information
provided on the primary vessel's nameplate, please
contact the Reflex Customer Service.
Reflexomat Information about the software version
V1.00
9.2.1

Default settings

The device controller is shipped with the following default settings. Use the
Customer menu to adjust these values to local conditions. In specific cases, it is
possible to further adjust the values in the Service menu.
Customer menu
Parameter Setting
Language DE
Minimum operating 1.8 bar
pressure "P "
0
Next maintenance 12 months
Volt-free contact YES
Make-up
Make-up "ON" 8 %
Make-up "OFF" 12 %
Maximum make-up
0 Litres
volume
Maximum make-up time 30 minutes
Maximum make-up cycles 6 cycles within
2 hours
Softening (Only if "With
softening Yes")
Shut off make-up No
Hardness reduction 8°dH
Maximum make-up 0 Litres
volume
Soft water capacity 0 Litres
Cartridge replacement 18 months
Controller
Comment
Display language.
see chapter 7.2 "Reflexomat
switching points" on page 10 .
Time left to the next due
maintenance.
see chapter 9.2.2 "Messages" on
page 14 .
Only if make-up has been
selected in the customer menu
with "With water meter Yes".
In the case of soft water residual
capacity = 0
= Target – Actual
Replace cartridge.
English — 13
