LANVIEW LEDs
The front panel LANVIEW LEDs indicate the status of the module and may be
used as an aid in troubleshooting. The 9E106-06 LANVIEW LEDs are shown in
Figure 4-1.
Diagnostic
Controller Status
FNB Receive
Ethernet
Transmit
ETHERNET
9E106-06
SMB
CPU
FNB
Figure 4-1. The LANVIEW LEDs
Chapter 4
System Status
FNB Transmit
Ethernet
Receive
4-1
