LANVIEW LEDs
The functions of the System Management Bus (SMB) and CPU LEDs are listed in
Table 4-1.
LED Color
Yellow (Flashing)
Yellow/Green
Red (Flashing)
The functions of the FNB Receive LED are listed in Table 4-1.
LED Color
Yellow (Flashing)
The functions of the FNB Transmit LED are listed in Table 4-3.
LED Color
Green (Flashing)
4-2
Table 4-1. SMB and CPU LEDs
State
Green Functional
Yellow Testing
Crippled
Booting
Red Reset
Failed
Off Power off
Table 4-2. FNB Receive LEDs
Activity (Flashing rate indicates rate of activity.)
Off No activity
Table 4-3. FNB Transmit LEDs
Activity (Flashing rate indicates rate of activity.)
Off No activity
Description
Fully operational.
Normal, internal diagnostic testing being
done.
Not fully operational (i.e., one bad port).
Blinks yellow and green while booting.
Normal power-up reset.
Fatal error has occurred.
Module powered off.
State
State
