LANVIEW LEDs

The front panel LANVIEW LEDs indicate the status of the module and may be
used as an aid in troubleshooting. Shown in Figure 4-1 are the LANVIEW LEDs of
the 9F116-01 module.
9F116-01
FNB Status
(Receive)
SMB
FNB
1
F
D
D
I
1
Figure 4-1. 9F116-01 LANVIEW LEDs
FDDI
System Status
CPU
FNB Status
(Transmit)
1
FDDI Status
A
B
