MMAC-Plus
™
Module Local Management
9E312-12 Module Specific Appendix
DRAFT
9031505

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMAC-Plus 9E312-12 and is the answer not in the manual?

Questions and answers

Related Manuals for Cabletron Systems MMAC-Plus 9E312-12

Summary of Contents for Cabletron Systems MMAC-Plus 9E312-12

  • Page 1 MMAC-Plus ™ Module Local Management 9E312-12 Module Specific Appendix DRAFT 9031505...

  • Page 2: Modifying Fields And User Privileges

    Information Introduction This appendix contains local management information that is specific to the 9E312-12 Ethernet Switch Module. The 9E312-12 Ethernet Switch Module is a 13-port switching module with: • 12 front panel Ethernet ports • 1 Internal Network Bus (INB) backplane port Each port of the 9E312-12 can be configured to operate in the Full Duplex mode.

  • Page 3: Module Interface Codes

    9E312-12 Module Specific Information Module Interface Codes The 9E312-12 Ethernet Switch Module has 15 interfaces. The table below lists the identifying number, name, and description of each interface. Interface Number Use the numbers listed in Table 1 to configure the module’s default interface (see the General Configuration Screen).

  • Page 4: Full Duplex Configuration Screen

    Full Duplex Configuration Screen The 9E312-12 Full Duplex Configuration Screen displays the port number, operation mode, link status, and port status of the module’s 12 ports. Module Name: 9E312-12 Slot Number: 10 PORT# SAVE MMAC-Plus LOCAL MANAGEMENT Full Duplex Configuration OPERATION MODE LINK STATUS STANDARD ENET...

  • Page 5: Full Duplex Configuration Screen Fields

    9E312-12 Module Specific Information Full Duplex Configuration Screen Fields PORT # (Read-only) - Displays the numbers for each of the Ethernet ports. OPERATION MODE (Modifiable) - This field lets you determine whether the specified port will transmit and receive data separately or simultaneously. You can set this field to one of the following values: •...
  • Page 6 PORT STATUS (Read-only) - Indicates whether the port has been turned on or off administratively. You will see one of the following values: • ENABLED - The port is turned on administratively. • DISABLED - The port is turned off administratively. Enable or disable ports from the Bridge Configuration screen.

  • Page 7: Port Statistics Screen

    9E312-12 Module Specific Information Port Statistics Screen The 9E312-12 Port Statistics Screen displays information and statistics about the module’s 12 Ethernet ports. Module Name: 9E312-12 Slot Number: 10 PACKETS: TOTAL ERRORS: COLLISIONS: CRC/ALIGNMENT ERRORS: UNDERSIZE PACKETS: OVERSIZE PACKETS: FRAGMENTS: JABBERS: PORT #: 1 MMAC-Plus LOCAL MANAGEMENT...

  • Page 8: Port Statistics Screen Fields

    Port Statistics Screen Fields PORT # (Read-only) - Indicates the current port for which statistics are displayed. OCTETS (Read-only) - Displays the number of bytes transmitted and received. PACKETS (Read-only) - Displays the number of frames transmitted and received. TOTAL ERRORS (Read-only) - Displays the total number of errors on this port. COLLISIONS (Read-only) - Displays the total number of collisions detected on this port.
  • Page 9 9E312-12 Module Specific Information PORT STATUS (Read-only) - Indicates the status of the selected port. Possible values are ENABLED and DISABLED. APPLICATION (Read-only) - Displays BRIDGING, indicating that the port is operating as a bridge with a high-speed backbone connection. OPERATION MODE (Read-only) - Displays one of the following values: •...
