Installing the 9E106-06 Module

Installing the EPIM

To install an EPIM:
When removing an EPIM, make sure to pull the module straight out so as not to
NOTE damage the connector.
1. Remove the coverplate or the EPIM (whichever applies).
2. Slide your new EPIM into place, making sure the connectors on the rear of the
module and inside the HUB attach properly. Refer to Figure 2-3.
3. Install the mounting screw.
2-4
Table 2-1. EPIM Board Revisions
EPIM
EPIM-T
EPIM-F2
EPIM-F1
EPIM-F3
EPIM-C
EPIM-A
EPIM-X
EPIM BOARD REVISION
04 or greater
05 or greater
05 or greater
02 or greater
05 or greater
Not Applicable
02 or greater
