7 Initial Configuration

General
At power-up the Radar will enter "Target Mode" and be ready to react to suitable targets after
approximately 1 minute assuming it is already configured.
The Radar's operating parameters can be configured at any time by accessing the relevant configuration
page on the web browser.
Assuming the Radar has not already been configured, entering the Radar's IP address
(192.168.1.105 is the default) in the laptop web browser address bar will after login (where "admin" is
default username and password) bring up the Status page. Note that for most configuration pages the
Radar will still be in "Target Mode" and so respond to targets as normal. However if in the Alignment,
Detection Zones or Camera pages, then the camera will not be moved to targets to allow the user to
operate the camera undisturbed.
Most pages have help text associated with them. Hovering over the blue question mark beside a menu
item will bring up relevant help text. Some icons also have help text.
Before starting configuration for the first time make sure that the camera image can be viewed on the
laptop as some of the set-up procedures will require it.
Note 1: To use a downloaded map to make set-up simpler, your laptop needs internet access.
Note2 : Changes made on a web-page have to be stored to the Radar using the Save or Set button on
the page - otherwise any changes made may be lost when you navigate away from the page or
close down the browser.
Status Page
The Status web page is the initial loading screen. It provides an overview of the Radar operation
including its "Overall Status", whether a schedule or detection zones are set and whether a camera is
connected or VMS set.
scan���
STATUS
Overall Status
Status
Initial Setup
Date & Time
Settings
l•Jetwork
Schedule
Raclar
Camer· a
Detection Zones
Alignment
Dete,:tion Zones
Date 8, Time Camera
\/rv1S EvBnt-:;
Camera Pop up -E:)
Tracking
Live Feed
VMS
Target Logs
System Logs
Disable Radar
Maintenance
Help
Copyright© Ogier Electronics Ltd 2016
Diagnostics
Status page screenshot
© 360 Vision Technology Ltd
Radar operating correctly
16/10/19 1045
Continuous detection
Set
Camera connected
Off
VMS connected
0
Page 14 of 78
Overall Radar
Status information
Disable Radar
Tick-box
