Summary of Contents for PR Lighting ARC LED 372
- Page 1 ARC LED 372 PR-8805 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD.
-
Page 2: Table Of Contents
Any future technical change in the user manual won’t be with any notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the projector source is not within the warranty. -
Page 3: Safety And Warnings
NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Warning User Electrical Goggles Protective Flames High Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector. Should there be any ●... -
Page 4: Instuctions
cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ● power mains. After running for 5minutes at constant temperature environment, the temperature of the housing of the ●... -
Page 5: Appearance
3. APPEARANCE Head Handle Power Supply Box 4. INSTALLATION OF BARN DOOR If the barn door is supplied, its installation is as follows: Place barn door support 14 via threads in the head 15, then use 4 screws 12 to mount the barn door on the barn door support to complete its completion. -
Page 6: Installation
5. INSTALLATION( For reference only) RIGGING ● Clamp Clamp Safety Cord Warning: please run the safety cord through the arm for safety. Handle Adjusting Knob Before moving the unit, lock the adjusting knob. Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp. -
Page 7: Dmx Control Connection
DMX CONTROL CONNECTION: ● Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 3 pin (which are included with the projector) or 3 pin XLR plugs and sockets. -
Page 8: Setup And Configuration
6. SETUP AND CONFIGURATION FRONT PANEL OPERATION ● Projector configuration can be set conveniently via push button and LCD display. Launch the projector and press button ENTER for more than 3 seconds to unlock the panel, the LCD will show the function menu of the projector, each main menu has its submenus and each submenu has a specific function. -
Page 9: Stand-Alone Mode
STAND-ALONE MODE ● Operate the projector without connecting with a controller, enable the master mode through the operation panel, the projector will run in Stand-Alone mode automatically. DMX address can be set at any number within 512. MASTER/SLAVE MODE ● Many projectors can run synchronously in the Master/Slave mode by linking them with each other. - Page 10 Blue 128-255 Default：English Language Setup English Chinese Backlight off 3 minutes after no Lcd Light Setup button pushed Display Invert Factory Setting PRM Transmit clean Progra LED Temperature Display of Lamp board temperature Fixture use Time XXXX INFO Display of Fixture time RDM Device Lab.
-
Page 11: Dmx Protocol
Note: 1. In one DMX chain, only one unit can be made as the master. Before master works, unplug its XLR cable connected with the console. 2. The parameters transmitted from the master include after several units are synchronized: DMX channel mode, display settings(display contrast excluded),operation mode(including user memory).During parameter transmission, set the unit transmitting data as master and others as slaves [1] If the unit is set as controlled by the timer, unit-on time is set as t1,unit-of as t2 and current time as t3... - Page 12 121-128 Pink 129-255 Rainbow effect with speed from slow to fast 000-255 Linear change from light to dark 000-255 Green Linear change from light to dark 000-255 Blue Linear change from light to dark 000-255 White Linear change from light to dark 000-007 Strobe 008-255...
-
Page 13: Led Indication
016-031 Speed 2 032-047 Speed 3 048-063 Speed 4 064-079 Speed 5 080-095 Speed 6 096-111 Speed 7 112-127 Speed 8 128-143 Speed 9 144-159 Speed 10 160-175 Speed 11 176-191 Speed 12 192-207 Speed 13 208-223 Speed 14 224-239 Speed 15 240-255 Speed 16, slowest... - Page 14 STROBE Electronic Strobe 0.5-33.FP.S. BEAM ANGLE Beam Angle(1/2peak) θ : 4.5° CONTROL: International Standard DMX512 Signal, 3 pin DMX512 interfaces Standard mode 6 channels, extended mode 11 channels, HSI color phase saturation mode 5 channels, HSIC color phase saturation color temperature mode 6 channels.
- Page 15 LIGHT OUTPUT( 45° lens) ° lux 13260 7718 3430 1929 1235 DISTANCE (m) DIAMETER (m) 0.43 0.85 2.55 1.28 1.70 2.13...
-
Page 16: Circuit Diagram And Pcb Connections
11. CIRCUIT DIAGRAM AND PCB CONNECTIONS CIRCUIT DIAGRAM ●... -
Page 17: Pcb Connections
PCB CONNECTIONS ●... - Page 18 PR-8805-MASTERBOARD ● LED driver input1 Optical sensor Power supply 温控 光敏传感器 电源 风扇 Signal input 信号输入 PWM signal PWM信号 Wireless board 无线 Thermal switch PR-8805-DRIVER BOARD ● PWM singnal input LED driver output2 LEDdriver output1 Power input ： PR-8805-LED LAMP BOARD ●...
-
Page 19: Component Order Codes
1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020614...
