ORiNG IPS-2042 Series User Manual

Industrial p.o.e. lite-managed ethernet switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Industrial P.O.E.
Lite-Managed Ethernet Switch
IPS-2042 SERIES User's Manual
Version 2.0
NOV, 2011.
ORing Industrial Networking Corp.
Website: www.oring-networking.com
E-mail:
support@oring-networking.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPS-2042 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ORiNG IPS-2042 Series

Summary of Contents for ORiNG IPS-2042 Series

  • Page 1 Industrial P.O.E. Lite-Managed Ethernet Switch IPS-2042 SERIES User’s Manual Version 2.0 NOV, 2011. ORing Industrial Networking Corp. Website: www.oring-networking.com E-mail: support@oring-networking.com...

  • Page 2: Table Of Contents

    Table of Content Getting to Know Your Switch ................ 3    About the IPS-2042 SERIES P.O.E Lite-Managed Industrial Switch ......3     Software Features ......................3     Hardware Features ......................3   Hardware Installation ..................4  Installing Switch on DIN-Rail ..................... 4  ...
  • Page 3 5.1.8.5 Ping Alive Check....................43     5.1.8.6 Scheduling ......................44     5.1.9 Save Configuration ......................45     5.1.10 Factory Default ......................45     5.1.11 System Reboot ......................45 Technical Specifications ................46  ORing Industrial Networking Corp.

  • Page 4: Getting To Know Your Switch

    SERIES switch has 4 X 10/100Base-T(X) P.S.E. (Power Sourcing Equipment) ports which are fully compliant with IEEE 802.3af standard. The IPS-2042 SERIES switch can be managed by WEB and a useful Window Utility we called Open-Vision. Open-Vision is powerful network management software.

  • Page 5: Hardware Installation

    IPS-2042 Series User’s Manual ardware Installation Installing Switch on DIN-Rail Each switch has a DIN-Rail kit on rear panel. The DIN-Rail kit helps switch to fix on the DIN-Rail. It is easy to install the switch on the DIN-Rail: 2.1.1 MountIPS-2042 SERIES on DIN-Rail DIN-Rail Size ORing Industrial Networking Corp.

  • Page 6: Wall Mounting Installation

    Each switch has another installation method for users to fix the switch. A wall mount panel can be found in the package. The following steps show how to mount the switch on the wall: Wall-Mounting size ORing Industrial Networking Corp.

  • Page 7: Hardware Overview

    IPS-2042 Series User’s Manual ardware Overview Front Panel The following table describes the labels that stick on the IPS-2042 SERIES. Port Description 10/100Base-T(X) RJ-45 fast Ethernet ports support 10/100 RJ-45 fast auto-negotiation. Ethernet ports Default Setting : Speed: auto Duplex: auto...
  • Page 8 7. Reset button. Push the button 3 seconds for reset; 5 seconds for factory default. 8. LED for P.O.E power supplied 9. 10/100Base-T(X) P.S.E. Ethernet ports.. 10. LED for Ethernet ACT status 11. LED for Ethernet LINK status 12. LED for Ethernet ACT/LINK status 13. 10/100Base-T(X) Ethernet ports.. ORing Industrial Networking Corp.
  • Page 9 IPS-2042 Series User’s Manual IPS-2042FX 1. LED for PWR1. When the PWR1 links, the green led will be light on. 2. LED for PWR2. When the PWR2 links, the green led will be light on. 3. LED for PWR3. When the PWR3 links, the green led will be light on.
  • Page 10 7. Reset button. Push the button 3 seconds for reset; 5 seconds for factory default. 8. LED for P.O.E power supplied 9. 10/100Base-T(X) P.S.E. Ethernet ports.. 10. LED for Ethernet ACT status 11. LED for Ethernet LINK status 12. LED for SFP ACT/LINK status 13. LED for SFP ports status. ORing Industrial Networking Corp.

  • Page 11: Front Panel Leds

    Data transmitted. Amber Port link up. Bottom Panel The bottom panel components of IPS-2042 SERIES are showed as below: 1. Terminal block includes: PWR1, PWR2 (+48V DC) and Relay output (1A@24VDC). 2. Power jack for PWR3 (+48VDC). IPS-2042 SERIES power connection...

  • Page 12: Cables

    Ethernet Cables The IPS-2042 SERIES switch has standard Ethernet ports. According to the link type, the switch use CAT 3, 4, 5, 5e UTP cables to connect to any other network device (PCs, servers, switches, routers, or hubs). Please refer to the following table for cable specifications.

  • Page 13: Fibers

    IPS-2042 Series User’s Manual MDI/MDI-X pins assignment Pin Number MDI port MDI-X port TD+(transmit) RD+(receive) TD-(transmit) RD-(receive) RD+(receive) TD+(transmit) P.O.E. power input + P.O.E. power input + P.O.E. power input + P.O.E. power input + RD-(receive) TD-(transmit) P.O.E. power input - P.O.E.

  • Page 14: Sfp

    The fiber optical ports are in multi-mode and single-mode with LC connector. Please remember that the TX port of Switch A should be connected to the RX port of Switch B. Switch A Switch B Fiber cord ORing Industrial Networking Corp.

  • Page 15: Web Management

    IPS-2042 Series User’s Manual EB Management Configuration by Web Browser This section introduces the configuration by Web browser. 5.1.1 About Web-based Management An embedded HTML web site resides in flash memory on the CPU board. It contains advanced management features and allows you to manage the switch from anywhere on the network through a standard web browser such as Microsoft Internet Explorer.
  • Page 16 3. The login screen appears. 4. Key in the username and password. The default username and password is “admin”. 5. Click “Enter” or “OK” button, then the main interface of the Web-based management appears. Login screen Main interface ORing Industrial Networking Corp.

  • Page 17: Basic Setting

    IPS-2042 Series User’s Manual 5.1.2 Basic Setting 5.1.2.1 Switch setting Switch setting interface The following table describes the labels in this screen. Label Description Assign the name of switch. The maximum length is 64 bytes System Name Display the description of switch.

  • Page 18: Ip Configuration

    IP on the DHCP server. Assign the IP address that the network is using. If DHCP client IP Address function is enabling, you do not need to assign the IP address. ORing Industrial Networking Corp.

  • Page 19: Sntp Configuration

    IPS-2042 Series User’s Manual The network DHCP server will assign the IP address for the switch and it will be displayed in this column. The default IP is 192.168.10.1 Assign the subnet mask for the IP address. If DHCP client Subnet Mask function is enabling, you do not need to assign the subnet mask.
  • Page 20 MEWT - Middle European Winter SWT - Swedish Winter EET - Eastern European, USSR +2 hours 2 pm Zone 1 BT - Baghdad, USSR Zone 2 +3 hours 3 pm ZP4 - USSR Zone 3 +4 hours 4 pm ORing Industrial Networking Corp.

  • Page 21: Lldp

    IPS-2042 Series User’s Manual ZP5 - USSR Zone 4 +5 hours 5 pm ZP6 - USSR Zone 5 +6 hours 6 pm WAST - West Australian Standard +7 hours 7 pm CCT - China Coast, USSR Zone 7 +8 hours...

  • Page 22: Backup & Restore

    TFTP Server IP Address Fill the file name. Restore File Name Click “restore” to restore the configurations. Restore Fill the file name. Restore File Name Click “restore” to restore the configurations. Restore Click “backup” to backup the configurations. Backup ORing Industrial Networking Corp.

  • Page 23: Upgrade Firmware

    The Fast Recovery Mode can be set to connect multiple ports to one or more switches. The IPS-2042 SERIES with its fast recovery mode will provide redundant links. Fast Recovery mode supports 4 priorities, only the first priority will be the act port, the other ports configured with other priority will be the backup ports.

  • Page 24: O-Ring

    There should be one and only one Ring Master in a ring. Ring Master However if there are two or more switches which set Ring Master to enable, the switch with the lowest MAC address will be the ORing Industrial Networking Corp.

  • Page 25: O-Chain

    IPS-2042 Series User’s Manual actual Ring Master and others will be Backup Masters. The primary port Ring Port The backup port Ring Port Mark to enable Coupling Ring. Coupling Ring can be used to Coupling Ring divide a big ring into two smaller rings to avoid effecting all switches when network topology change.
  • Page 26 Choosing the port which connect to the ring Ring Port In the O-Chain application, the head and tail of two Switch Port, Edge Port must start the Edge,MAC smaller Switch, Edge port will be the backup and RM LED Light. ORing Industrial Networking Corp.

  • Page 27: Open-Ring

    IPS-2042 Series User’s Manual 5.1.3.4 Open-Ring Open-Ring technology can be applied for other vendor’s proprietary ring. Thus, you can add switches of ORing into the network constructed by other ring technology and enable Open-Ring to co-operate with other vendor’s managed switch. Open-Ring interface...

  • Page 28: Rstp

    You can enable/disable the RSTP function, and set the parameters for each port. RSTP Setting interface The following table describes the labels in this screen. Label Description You must enable or disable RSTP function before configuring the RSTP mode related parameters. ORing Industrial Networking Corp.
  • Page 29 IPS-2042 Series User’s Manual A value used to identify the root bridge. The bridge with the Priority (0-61440) lowest value has the highest priority and is selected as the root. If the value changes, you must reboot the switch. The value must be multiple of 4096 according to the protocol standard rule.

  • Page 30: Port Configuration

    RSTP Information Show RSTP algorithm result at this table. RSTP Information interface 5.1.4 Port Configuration 5.1.4.1 Port Control By this function, you can set the state, speed/duplex, flow control, and security of the port. Port Control interface ORing Industrial Networking Corp.

  • Page 31: Port Status

    IPS-2042 Series User’s Manual The following table describes the labels in this screen. Label Description Port number for setting. Port NO. Enable/Disable the port. State You can set Auto-negotiation, 100 full,100 half,10 full,10 half Speed/Duplex mode. Support symmetric and asymmetric mode to avoid packet loss Flow Control when congestion occurred.

  • Page 32: Vlan

    VLAN Configuration – Port Based VLAN interface The following table describes the labels in this screen. Label Description Mark the blank to assign the port into VLAN group. Group Click “Apply” to activate the configurations. Apply Show help file. Help ORing Industrial Networking Corp.

  • Page 33: Snmp Configuration

    IPS-2042 Series User’s Manual 5.1.6 SNMP Configuration Simple Network Management Protocol (SNMP) is the protocol developed to manage nodes (servers, workstations, routers, switches and hubs etc.) on an IP network. SNMP enables network administrators to manage network performance, find and solve network problems, and plan for network growth.

  • Page 34: Snmp -Trap Setting

    Label Description The server IP address to receive Trap Server IP Community for authentication Community Trap Version supports V1 and V2c. Trap Version Add trap server profile. Remove trap server profile. Remove Show help file. Help ORing Industrial Networking Corp.

  • Page 35: Snmp - Snmp-V3 Setting

    IPS-2042 Series User’s Manual 5.1.6.3 SNMP – SNMP-V3 Setting ORing Industrial Networking Corp.
  • Page 36 2. ViewName: set up the name. 3. Sub-Oid Tree: fill the Sub OID. 4. Type: select the type – exclude or included. 5. Click "Add" to add context name. 6. Click "Remove" to remove unwanted context name. Show help file. Help ORing Industrial Networking Corp.

  • Page 37: System Warning

    IPS-2042 Series User’s Manual 5.1.7 System Warning Warning function is very important for managing switch. You can manage switch by SYSLOG, E-MAIL, and Fault Relay. It helps you to monitor the switch status on remote site. When events occurred, the warning message will send to your appointed server, E-MAIL, or relay fault to switch panel.

  • Page 38: System Event Log

    Show help file. Help 5.1.7.3 SMTP Setting The SMTP is Short for Simple Mail Transfer Protocol. It is a protocol for e-mail transmission across the Internet. Please refer to RFC 821 - Simple Mail Transfer Protocol. ORing Industrial Networking Corp.
  • Page 39 IPS-2042 Series User’s Manual System Warning – SMTP Setting interface The following table describes the labels in this screen. Label Description Enable/Disable transmission system warning events by e-mail. E-mail Alarm The SMTP server IP address Sender E-mail Address The Subject of the mail Mail Subject Username: the authentication username.

  • Page 40: Event Selection

    System Cold Start Alert when O-Ring topology change O-Ring Topology Change  Port Event Disable  Link Up  Link Down  Link Up & Link Down Click “Apply” to activate the configurations. Apply Show help file. Help ORing Industrial Networking Corp.

  • Page 41: Fault Relay Alarm

    IPS-2042 Series User’s Manual 5.1.7.5 Fault Relay Alarm When any selected fault event is happened, the Fault LED in switch panel will light up and the electric relay will signal at the same time. Fault alarm interface 5.1.8 Power Over Ethernet (P.O.E.) 5.1.8.1 Basic Setting...

  • Page 42: Port Setting

    PoE switch can provide the power to those PD devices Set port priority for the P.O.E. power management. 1 = C (critical), Priority 2 = H (High), 3 = L (Low) Set the power limit value. The maximum value must less 15400 Power Limit ORing Industrial Networking Corp.

  • Page 43: Port Status

    IPS-2042 Series User’s Manual 5.1.8.3 Port Status Show P.O.E each Port, the situation in detail. Label Description Port number. Port P.S.E Function Port Link or Down Link Show P.S.E Status. State Set the “Power Limit From Classification” function for each Power Limit From P.O.E.

  • Page 44: Ping Alive Check

    Note down " Ping Check " a result of movement after starting. Failure Log Set up movements wanted to carry out Failure Action Switch ping check failure " P.O.E " restarts the buffer time of Reboot Time switch. ORing Industrial Networking Corp.

  • Page 45: Scheduling

    IPS-2042 Series User’s Manual 5.1.8.6 Scheduling User can appointed date and time, Enable or Close Power Over Ethernet Function, switch can with according to the time when is set up, carry on the designated movements (SNTP Function must Enable) The following table describes the labels in this screen.

  • Page 46: Save Configuration

    You can select “Keep current IP address setting” and “Keep current username & password” to prevent IP and username & password from default. 5.1.11 System Reboot System Reboot interface ORing Industrial Networking Corp.

  • Page 47: Technical Specifications

    IPS-2042 Series User’s Manual echnical Specifications ORing Switch Model IPS-2042TX IPS-2042FX-MM-SC IPS-2042FX-SS-SC Physical Ports 10/100 Base-T(X) Ports in RJ45 Auto MDI/MDIX with P.S.E. 10/100 Base-T(X) Ports in RJ45 Auto MDI/MDIX without P.S.E. Fiber Ports Number Fiber Ports Standard 100Base-FX 100Base-FX...
  • Page 48 IEEE 802.3af PoE specification (up to 25 Watts per port for P.S.E.) MAC Table 2048 MAC addresses Priority Queues Processing Store-and-Forward Switching bandwidth: 1.2Gbps Switch Properties VLAN: Port Based Enable/disable ports Security Features VLAN to segregate and secure network traffic ORing Industrial Networking Corp.
  • Page 49 IPS-2042 Series User’s Manual SNMPv3 encrypted authentication and access security STP/RSTP (IEEE 802.1D/w) Redundant Ring (O-Ring) with recovery time less than 10ms over 250 units Software Features Open-Ring support the other vendor’s ring technology in open architecture Port configuration, status, statistics, monitoring, security...
