SPALDING In-Ground Basketball System Owner's Manual page 11

7.
TWO people are required to lift pole into
position so that the threaded assembly
rod (14) can be installed and secured by
the THIRD person.
While pole is being supported by TWO
capable adults, position rod (14) and lock
into place with hitch pin (36) and cotter
pin (37).
Slide barrel washer (35) onto other end
of rod (14) and secure with washer (24)
and nut (26). Tighten nut (26) until it is
positioned at 3-3/4" from the end of the
rod (14) as shown (Figure A).
THREE CAPABLE ADULTS
REQUIRED FOR THIS
PROCEDURE. FAILURE
TO FOLLOW THIS
WARNING COULD RESULT
IN SERIOUS INJURY AND/
OR PROPERTY DAMAGE.
26
24
35
14
WARNING!
Completed Assembly
37
36
11
1
1
26
FIGURE A.
14
