Rest top of pole (1) on a piece of scrap wood (not included) and line up holes in pole to holes in
6A.
mounting plate (2) as shown.
WARNING!
THREE CAPABLE ADULTS
REQUIRED FOR THIS
PROCEDURE. FAILURE
TO FOLLOW THIS
WARNING COULD RESULT
IN SERIOUS INJURY AND/
OR PROPERTY DAMAGE.
2
Insert bolt (28) through holes in plate and pole and secure with nut (22).
6B.
PLAYING SURFACE
28
PLAYING SURFACE
PLAYING SURFACE
1
PLAYING SURFACE
10
1
SCRAP WOOD
(NOT INCLUDED)
1
22
