CYP CPLUS-V4H2HA Operation Manual page 16

COMMAND
Description and Parameters
GET DISPLAY N1 UART BAUD RATE
Show the current baud rate of the specified RS-232 port.
Available values for N1:
A
B
SET DISPLAY N1 UART DATA BIT N2
Set the data bits for the specified RS-232 port.
Available values for N1:
A
B
Available values for N2:
7
8
GET DISPLAY N1 UART DATA BIT
Show the current number of data bits of the specified RS-232 port.
Available values for N1:
A
B
SET DISPLAY N1 UART PARITY N2
Set the parity of the specified RS-232 port.
Available values for N1:
A
B
Available values for N2:
0
1
2
GET DISPLAY N1 UART PARITY
Show the current parity setting of the specified RS-232 port.
Available values for N1:
A
B
11
[Output A]
[Output B]
[Output A]
[Output B]
[7 data bits]
[8 data bits]
[Output A]
[Output B]
[Output A]
[Output B]
[None]
[Odd]
[Even]
[Output A]
[Output B]
