Bosch Rexroth AG

Technical data

This is a product that corresponds to the limit values of the emitted
interference of class A (industrial environments), but not of class B
(residential area and small enterprises).
When using the product in residential areas or small enterprises, the
operator has to take actions to prevent radio interferences (also
refer to DIN EN 55022).
7 Technical data

7.1 Field bus

Field bus
Number
Connection method
Transfer rate
MAC address

7.2 Power supply

The module bus connector supplies the SafeLogic compact Sercos Gateway with
power.
Supply voltage
Nominal current
Power consumption
Type of supply voltage

7.3 Safety-related characteristic parameters

Safety integrity level SIL
Safety integrity claim limit (SIL)
Category
Performance level PL
PFH (average frequency of a dangerous failure per
hour)
PFD (average probability of a dangerous failure
avg
in case of request)
10/31
Sercos
2
RJ-45 socket
100 MBit/s (100Base-TX)
Saved on electronic type plate, can be read out via
the configuration tool
24 V DC (16.8 V DC .... 24 V DC .... 30 V DC)
Typ. 110 mA (if nominal current is 24 V DC)
Max. 2.7 W
PELV or SELV (provided via SLC-3-CPU). For the
power supply unit requirements refer to the
instruction "IndraControl SafeLogic compact
Hardware", see tab. 1-2 "Required and
supplementing documentation" on page
SIL 3 (IEC 61508)
SIL CL3 (EN 62061)
Category 4 (DIN EN ISO 13849-1)
PL e (DIN EN ISO 13849-1)
0.4 × 10 -9 1/h
3.5 × 10 -5
DOK-CONTRL -SLC*GW*GS3S-IT03-EN-P
Sercos Gateway
2.
