Sercos Gateway
Climatic ambient conditions and characteristics
Mechanic ambient conditions and characteristics
Mounting position
Vibration resistance
Shock resistance
Continuous shock
Single shock
Free fall
Electromagnetic operating conditions and characteristics
EMC
Tab. 6-1: Overview on all ambient conditions
NOTICE
Due to the risk of corrosion, avoid sulphurous gases (e.g. sulphur dioxide (SO
and hydrogen suphide (H
NOTICE
The ambient air must not contain acids, alkaline solutions, corrosive agents,
●
salts, metal vapors and other electrically conductive contaminants in high
concentrations
The devices to be installed into the housing and installation compartments
●
must at least comply with the degree of protection IP 54 according to DIN EN
60529.
The device shall be provided in a suitable fire enclosure in the end-use
●
application.
DOK-CONTRL -SLC*GW*GS3S-IT03-EN-P
In operation
Vertical mounting on rail to DIN EN
60715
10 Hz - 500 Hz/3 g
(EN 60 068-2-6)
10 g, 16 ms (EN 60 068-2-29)
30 g, 11 ms (EN 60 068-2-27)
-
Class A
(EN 61000-6-2, EN 55011)
Defective product due to gases jeopardizing
functions
S)). The product is not resistant against these gases.
2
Failure of the product due to contaminated air
Bosch Rexroth AG
Ambient conditions
Storage and transport
–
–
–
With product packaging, the
height of fall is 300 mm
With shipping packaging, the
height of fall is 1000 mm
Acc. to DIN EN 60068-2-32,
method 1
–
)
2
9/31
