Configuration
5.3.4

CAN Configuration

From the PC connected to Access Point unit 2:
1. Navigate to the web interface of each Wireless Bolt CAN unit.
2. Select the CAN Settings tab.
3. Configure the CAN port settings:
CAN Settings
Operating
Mode
CAN Bitrate
CAN Ethernet
Protocol
CAN Simple ID
Extended
Frame
®
Anybus Wireless Bolt CAN
Select Operation Mode On (Default) or Off.
Select a CAN Bitrate.
Optimized (Default)
Use this protocol when bridging two CAN buses using multiple Bolt
CAN devices. Data is transferred using a raw binary encoding that
maximizes the performance and minimizes the bandwidth.
SLCAN
Use the ASCII based SLCAN protocol to bridge CAN traffic to a
custom endpoint. CAN frames can be sent and received via a TCP/
IP socket using basic commands. The command starts with a letter
followed by a number of hexadecimal digits and ends with a
carriage return (character code 0x0D).
Simple
In this mode the raw bytes of any incoming TCP payload will be
transparently copied into the data segment of one or multiple CAN
frames. The frame ID can be specified in the CAN Simple ID field.
Only the data segment of any incoming CAN frames will be
transparently copied to the outgoing TCP stream, with no markers
indicating where contents of one frame ends and the next one
begins. Incoming frames will still be subject to the CAN RX filter.
Active when the Simple CAN Ethernet Protocol is selected.
Specify the frame ID to use.
Active when the Simple CAN Ethernet Protocol is selected.
Extended Frame defines if the CAN Simple ID should be standard
or extended.
By default, Standard Frame is used.
Select the checkbox to enable Extended Frame.
™
