eBP-4A3B0
4-Slot ePCI Passive Backplane
Board Rev.
0
Quick REFERENCE
Version 1.2
First Level Debugging
1. If ATX +12V power supply is used on SHB, make sure that the +12V power cable (J19) is
conected in SHB and +12V power supply cable mated in J17.
2. Remove all peripheral boards and SBCs.
3. Remove all cables from backplane.
4. Make sure that all the Power Good LEDs are on.
J3
J2
J1
J21
J28
J26
J 33 J35 J32 J34 J31
Connectors
J1-3: PCI Connector
J21: ePCI Connector
J22: FAN Connector
J26: Keyboard Mouse Connector J34: Reset Button
J28: Multifunction Connector
J29
J31: Power Button Connector
J32: Speaker Connector
J33: Power-LED
J35: IDE LED
J30
J22
